16-86 FC Port REF 1
Range: Function:
0
*
[0 - 0] View the two-byte Status word (STW) sent to the Bus-Master.
Interpretation of the Status word depends on the fieldbus option
installed and the Control word profile selected in par. 8-10.
2.17.8. 16-9* Diagnosis Read-Out
Parameters displaying alarm, warning and extended status words.
16-90 Alarm Word
Range: Function:
0
*
[0 - FFFFFFFF] View the alarm word sent via the serial communication port in
hex code.
16-90 Alarm Word 2
Range: Function:
0
*
[0 - FFFFFFFF] View the alarm word sent via the serial communication port in
hex code.
16-92 Warning Word
Range: Function:
0
*
[0 - FFFFFFFF] View the warning word sent via the serial communication port
in hex code.
16-93 Warning Word 2
Range: Function:
0
*
[0 - FFFF] View the warning word sent via the serial communication port
in hex code.
16-94 Ext. Status Word
Range: Function:
0
*
[0 - FFFF] Returns the extended warning word sent via the serial commu-
nication port in hex code.
2.18. Parameters: Encoder Input
2.18.1. 17-** Motor Feedb. Option
Additional parameters to configure the Encoder (MCB102) or the Resolver (MCB103) Feedback
Option.
