2.17. Parameters: Data Read-outs
2.17.1. 16-** Data Readouts
Parameter group for data read-outs, e.g. actual references, voltages, control, alarm, warning and
status words.
2.17.2. 16-0* General Status
Parameters for reading the general status, e.g. the calculated reference, the active control word,
status.
16-00 Control Word
Range: Function:
0
*
[0 - FFFF] View the Control word sent from the frequency converter via the
serial communication port in hex code.
16-01 Reference [Unit]
Range: Function:
0.000
*
[-999999.000 -
999999.000]
View the present reference value applied on impulse or analog
basis in the unit resulting from the configuration selected in par.
1-00 (Hz, Nm or RPM).
16-02 -200.0 - 200.0 %
Range: Function:
0.0%
*
[] View the total reference. The total reference is the sum of dig-
ital, analog, preset, bus, and freeze references, plus catch-up
and slow-down.
16-03 Status Word
Range: Function:
0
*
[0 - FFFF] View the Status word sent from the frequency converter via the
serial communication port in hex code.
16-05 Main Actual Value [%]
Range: Function:
0%
*
[-100 to +100%] View the two-byte word sent with the Status word to the bus
Master reporting the Main Actual Value.
16-09 Custom Readout
Range: Function:
0.00
unit
*
[x.xx - x.xx unit] View the value of custom readout from par. 0-30 to par. 0-32
