Danfoss FC 300

6-61 Term. X30/8 Output Min Scale
Range: Function:
0%
*
[0.00 - 200 %] Scales the minimum output of the selected analog signal on ter-
minal X30/8. Scale the minimum value as a percentage of the
maximum signal value, i.e. 0 mA (or 0 Hz) is desired at 25% of
the maximum output value and 25% is programmed. The value
can never be higher than the corresponding setting in par. 6-62
if value is below 100%.
This parameter is active when option module MCB 101 is moun-
ted in the frequency converter.
6-62 Term. X30/8 Output Max Scale
Range: Function:
100%
*
[0.00 - 200 %] Scales the maximum output of the selected analog signal on
terminal X30/8. Scale the value to the desired maximum value
of the current signal output. Scale the output to give a lower
current than 20 mA at full scale or 20 mA at an output below
100% of the maximum signal value. If 20 mA is the desired
output current at a value between 0 - 100% of the ful-scale
output, program the percentage value in the parameter, i.e.
50% = 20 mA. If a current between 4 and 20 mA is desired at
maximum output (100%), calculate the percentage value as
follows:
20 mA / desired maximum current x 100 %
i . e .10 mA :
20
10
x 100 = 200 %
2.10. Parameters: Controllers
2.10.1. 7-** Controllers
Parameter group for configuring application controls.
2.10.2. 7-0* Speed PID Ctrl.
Parameters for configuring the speed PID control.
7-00 Speed PID Feedback Source
Option: Function:
Select the encoder for closed loop feedback.
The feedback may come from a different encoder (typically
mounted on the application itself) than the motor mounted en-
coder feedback selected in par. 1-02.
This parameter cannot be adjusted while the motor is running.
[0] Motor feedb. p.1-02
(FC 302 only)
[1] 24V encoder
[2] MCB 102
[3] MCB 103
[4] MCO encoder 1
FC 300 Programming Guide 2. How to Programme
MG.33.M2.02 - VLT
®
is a registered Danfoss trademark 121
2
