Danfoss FC 300

[102] Reference (Ref min-
max), 4.20 mA
Feedback (FB min-
max)0.20 mA
[103] Feedback (FB min-
max) 4.20 mA
Motor current (0-Im-
ax) 0.20 mA
[104] Motor current (0-Im-
ax) 4.20 mA
Torque relative to lim-
it0-Tlim,0.20 mA
[105] Torque relative to lim-
it 0-Tlim, 4.20 mA
Torque relativetora-
ted0-Tnom,0.20 mA
[106] Torque relative to rat-
ed 0-Tnom, 4.20 mA
Power (0-Pnom),0.20
mA
[107] Power (0-Pnom), 4.20
mA
Speed (0-Speedmax),
0.20 mA
[108] Speed (0-Speedmax),
4.20 mA
Torque (+/-160%
torque), 0-20 mA
[130] Torque (+/-160%
torque), 4-20 mA
Output freq. 4-20 mA
[131] Reference 4-20 mA
[132] Feedback 4-20 mA
[133] Motor cur. 4-20 mA
[134] Torque % lim. 4-20
mA
[135] Torque % nom 4-20
mA
[136] Power 4-20 mA
[137] Speed 4-20 mA
[138] Torque 4-20 mA
[139] Bus Ctrl 0-20 mA
[140] Bus Ctrl 4-20 mA
[141] Bus Ctrl 0-20 mA,
Timeout
[142] Bus Ctrl 4-20 mA,
Timeout
[150] Max Out Freq 4-20
mA
