Danfoss FC 300

2.17.3. 16-1* Motor Status
Parameters for reading the motor status values.
16-10 Power [kW]
Range: Function:
0.0kW
*
[0.0 - 1000.0 kW] View the motor power in kW. The value shown is calculated on
the basis of the actual motor voltage and motor current. The
value is filtered, and therefore approx. 30 ms may pass from
when an input value changes to when the data read-out values
change.
16-11 Power [hp]
Range: Function:
0.00hp
*
[0.00 - 1000.00 hp] View the motor power in hp. The value shown is calculated on
the basis of the actual motor voltage and motor current. The
value is filtered, and therefore approx. 30 ms may pass from
when an input value changes to when the data read-out values
change.
16-12 Motor Voltage
Range: Function:
0.0V
*
[0.0 - 6000.0 V] View the motor voltage, a calculated value used for controlling
the motor.
16-13 Motor Frequency
Range: Function:
0.0Hz
*
[0.0 - 6500.0 Hz] View the motor frequency, without resonance dampening.
16-14 Motor Current
Range: Function:
0.00A
*
[0.00 - 0.00 A] View the motor current measured as a mean value, IRMS. The
value is filtered, and thus approx. 30 ms may pass from when
an input value changes to when the data read-out values
change.
16-15 Frequency [%]
Range: Function:
0.00%
*
[0.00 - 0.00 %] View a two-byte word reporting the actual motor frequency
(without resonance dampening) as a percentage (scale
0000-4000 Hex) of par. 4-19
Max. Output Frequency . Set par.
9-16 index 1 to send it with the Status Word instead of the MAV.
