Danfoss FC 300

16-16 Torque
Range: Function:
0.0Nm
*
[-3000.0 - 3000.0
Nm]
View the torque value with sign, applied to the motor shaft.
Linearity is not exact between 160% motor current and torque
in relation to the rated torque. Some motors supply more than
160% torque. Consequently, the min. value and the max. value
will depend on the max. motor current as well as the motor
used. The value is filtered, and thus approx. 30 ms may pass
from when an input changes value to when the data read-out
values change.
16-17 Speed [RPM]
Range: Function:
0 RPM
*
[0 - 0 RPM] View the actual motor RPM. In open loop or closed loop process
control the motor RPM is estimated. In speed closed loop modes
the motor RPM is measured.
16-18 Motor Thermal
Range: Function:
0 %
*
[0 - 100 %] View the calculated thermal load on the motor. The cut-out limit
is 100%. The basis for calculation is the ETR function selected
in par.1-90.
16-19 KTY Sensor Temperature
Range: Function:
0°C
*
[0 - xxx °C] Returning the actual temperature on KTY sensor buil into the
motor.
See par. 1-9*.
16-20 Motor Angle
Range: Function:
0
*
[0 - 65535] View the current encoder/resolver angle offset relative to the
index position. The value range of 0-65535 corresponds to
0-2*pi (radians).
16-22 Torque [%]
Range: Function:
0%
*
[-200 - 200%] Value shown is the torque in percent of nominal torque, with
sign, applied to the motor shaft.
2.17.4. 16-3* Drive Status
Parameters for reporting the status of the frequency converter.
