16-75 Analog In X30/11
Range: Function:
0.000
*
[0.000 - 0.000] View the actual value at input X30/11 of MCB 101.
16-76 Analog In X30/12
Range: Function:
0.000
*
[0.000 - 0.000] View the actual value at input X30/12 of MCB 101.
16-77 Analog Out X30/8 16-77 [mA]
Range: Function:
0.000
*
[0.000 - 0.000] View the actual value at input X30/8 in mA.
2.17.7. 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control words.
16-80 Fieldbus CTW 1
Range: Function:
0
*
[0 - 65535] View the two-byte Control word (CTW) received from the Bus-
Master. Interpretation of the Control word depends on the
fieldbus option installed and the Control word profile selected in
par. 8-10.
For more information please refer to the relevant fieldbus man-
ual.
16-82 Fieldbus REF 1
Range: Function:
0
*
[-200 - 200] View the two-byte word sent with the control word form the
Bus-Master to set the reference value.
For more information please refer to the relevant fieldbus man-
ual.
16-84 Comm. Option STW
Range: Function:
0
*
[0 - 65535] View the extended fieldbus comm. option status word.
For more information please refer to the relevant fieldbus man-
ual.
16-85 FC Port CTW 1
Range: Function:
0
*
[0 - 65535] View the two-byte Control word (CTW) received from the Bus-
Master. Interpretation of the control word depends on the field-
bus option installed and the Control word profile selected in par.
8-10.
FC 300 Programming Guide 2. How to Programme
MG.33.M2.02 - VLT
®
is a registered Danfoss trademark
197
