Danfoss FC 300

[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7 Select the first boolean (TRUE or FALSE) input for the selected
logic rule.
See par. 13-01
Start Event ([0] - [61]) and par. 13-02 Stop
Event
([70] - [74]) for further description.
13-41 Logic Rule Operator 1
Array [6]
Select the first logical operator to use on the Boolean inputs
from par. 13-40 and 13-42.
[13 -XX] signifies the boolean input of par. 13-*.
[0]
*
DISABLED Ignores par. 13-42, 13-43, and 13-44.
[1] AND evaluates the expression [13-40] AND [13-42].
[2] OR evaluates the expression [13-40] OR [13-42].
[3] AND NOT evaluates the expression [13-40] AND NOT [13-42].
[4] OR NOT evaluates the expression [13-40] OR NOT [13-42].
[5] NOT AND evaluates the expression NOT [13-40] AND [13-42].
[6] Not or evaluates the expression NOT [13-40] OR [13-42].
[7] Not and not evaluates the expression NOT [13-40] AND NOT [13-42].
[8] Not or not evaluates the expression NOT [13-40] OR NOT [13-42].
13-42 Logic Rule Boolean 2
Array [6]
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
2. How to Programme FC 300 Programming Guide
164 MG.33.M2.02 - VLT
®
is a registered Danfoss trademark
2
