[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7 Select the second boolean (TRUE or FALSE) input for the selec-
ted logic rule. See par. 13-01
Start Event ([0] - [61]) and par.
13-02
Stop Event ([70] - [74]) for further description.
13-43 Logic Rule Operator 2
Array [6]
Select the second logical operator to be used on the boolean
input calculated in par. 13-40, 13-41, and 13-42, and the boo-
lean input coming from par. 13-42.
[13-44] signifies the boolean input of par. 13-44.
[13-40/13-42] signifies the boolean input calculated in par.
13-40, 13-41, and 13-42. DISABLED [0] (factory setting). select
this option to ignore par. 13-44.
[0]
*
DISABLED
[1] AND Evaluates the expression [13-40/13-42] AND [13-44].
[2] OR Evaluates the expression [13-40/13-42] OR [13-44].
[3] AND NOT Evaluates the expression [13-40/13-42] AND NOT [13-44].
[4] OR NOT Evaluates the expression [13-40/13-42] OR NOT [13-44].
[5] NOT AND evaluates the expression NOT [13-40/13-42] AND [13-44].
[6] NOT OR Evaluates the expression NOT [13-40/13-42] OR [13-44].
[7] NOT AND NOT Evaluates the expression NOT [13-40/13-42] and evaluates
AND NOT [13-44].
[8] NOT OR NOT Evaluates the expression NOT [13-40/13-42] OR NOT [13-44].
13-44 Logic Rule Boolean 3
Array [6]
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
