Danfoss FC 300

14-20 Reset Mode
Option: Function:
[0]
*
Manual reset
[1] Automatic reset x 1
[2] Automatic reset x 2
[3] Automatic reset x 3
[4] Automatic reset x 4
[5] Automatic reset x 5
[6] Automatic reset x 6
[7] Automatic reset x 7
[8] Automatic reset x 8
[9] Automatic reset x 9
[10] Automatic reset x 10
[11] Automatic reset x 15
[12] Automatic reset x 20
[13] Infinite Automatic Re-
set
Select the reset function after tripping. Once reset, the drive can
be restarted.
Select
Manual reset [0], to perform a reset via [RESET] or via
the digital inputs.
Select
Automatic reset x 1…x20 [1]-[12] to perform between
one and twenty automatic resets after tripping.
Select
Infinite Automatic Reset [13] for continuous resetting af-
ter tripping.
NB!
The motor may start without warning. If the speci-
fied number of AUTOMATIC RESETs is reached
within 10 minutes, the drive enters Manual reset
[0] mode. After the Manual reset is performed, the
setting of par. 14-20 reverts to the original selec-
tion. If the number of automatic resets is not
reached within 10 minutes, or when a Manual re-
set is performed, the internal AUTOMATIC RESET
counter returns to zero.
NB!
Automatic reset will also be active for resetting
safe stop function in firmware version < 4.3x.
14-21 Automatic Restart Time
Range: Function:
10s
*
[0 - 600 s] Enter the time interval from trip to start of the automatic reset
function. This parameter is active when par. 14-20 is set to
Automatic reset [1] - [13].
FC 300 Programming Guide 2. How to Programme
MG.33.M2.02 - VLT
®
is a registered Danfoss trademark 175
2
