This parameter cannot be adjusted while the motor is running.
The value depends on setting in par. 17-20.
17-24 SSI Data Length
Range: Function:
13
*
[13 - 25] Set the number of bits for the SSI telegram. Choose 13 bits for
single-turn encoders and 25 bits for multi-turn encoder.
17-25 Clock Rate
Range: Function:
260kHz
*
[100 - 260 kHz] Set the SSI clock rate. With long encoder cables the clock rate
must be reduced.
17-26 SSI Data Format
Option: Function:
[0]
*
Gray Code
[1] Binary Code Set the data format of the SSI data. Choose between Gray or
Binary format.
17-34 HIPERFACE Baudrate
Option: Function:
[0] 600
[1] 1200
[2] 2400
[3] 4800
[4]
*
9600
[5] 19200
[6] 38400 Select the baud rate of the attached encoder.
This parameter cannot be adjusted while the motor is running.
The parameter is only accessible when par. 17-20 is set to HI-
PERFACE [1].
2.18.4. 17-5* Resolver Interface
Parameter group 17-5* is used for setting parameters for the MCB 103 Resolver Option.
Usually the resolver feedback is used as motor feedback from Permanent Magnet motors with par.
1-01 set to Flux with motor feedback.
Resolver parameters cannot be adjusted while the motor is running.
17-50 Resolver Poles
Range: Function:
2
*
[2-2] Set the number of poles on the resolver.
The value is stated in the data sheet for resolvers.
