Par. No. # Parameter description Default value 4-set-up FC 302
only
Change during op-
eration
Conver-
sion index
Type
14-0* Inverter Switching
14-00 Switching Pattern [1] SFAVM All set-ups TRUE - Uint8
14-01 Switching Frequency null All set-ups TRUE - Uint8
14-03 Overmodulation [1] On All set-ups FALSE - Uint8
14-04 PWM Random [0] Off All set-ups TRUE - Uint8
14-1* Mains On/Off
14-10 Mains Failure [0] No function All set-ups FALSE - Uint8
14-11 Mains Voltage at Mains Fault ExpressionLimit All set-ups TRUE 0 Uint16
14-12 Function at Mains Imbalance [0] Trip All set-ups TRUE - Uint8
14-2* Trip Reset
14-20 Reset Mode [0] Manual reset All set-ups TRUE - Uint8
14-21 Automatic Restart Time 10 s All set-ups TRUE 0 Uint16
14-22 Operation Mode [0] Normal operation All set-ups TRUE - Uint8
14-23 Typecode Setting null 2 set-ups FALSE - Uint8
14-25 Trip Delay at Torque Limit 60 s All set-ups TRUE 0 Uint8
14-26 Trip Delay at Inverter Fault ExpressionLimit All set-ups TRUE 0 Uint8
14-28 Production Settings [0] No action All set-ups TRUE - Uint8
14-29
Service Code 0 N/A All set-ups TRUE 0 Int32
14-3* Current Limit Ctrl.
14-30 Current Lim Cont, Proportional Gain 100 % All set-ups FALSE 0 Uint16
14-31 Current Lim Contr, Integration Time 0.020 s All set-ups FALSE -3 Uint16
14-4* Energy Optimising
14-40 VT Level 66 % All set-ups FALSE 0 Uint8
14-41 AEO Minimum Magnetisation 40 % All set-ups TRUE 0 Uint8
14-42 Minimum AEO Frequency 10 Hz All set-ups TRUE 0 Uint8
14-43
Motor Cosphi ExpressionLimit All set-ups TRUE -2 Uint16
14-5* Environment
14-50 RFI Filter [1] On 1 set-up x FALSE - Uint8
14-52 Fan Control [0] Auto All set-ups TRUE - Uint8
14-53 Fan Monitor [1] Warning All set-ups TRUE - Uint8
14-55 Output Filter [0] No Filter 1 set-up FALSE - Uint8
14-56 Capacitance Output Filter 2.0 uF 1 set-up FALSE -7 Uint16
14-57 Inductance Output Filter 7.000 mH 1 set-up FALSE -6 Uint16
14-7* Compatibility
14-72 VLT Alarm Word 0 N/A All set-ups FALSE 0 Uint32
14-73 VLT Warning Word 0 N/A All set-ups FALSE 0 Uint32
14-74 VLT Ext. Status Word 0 N/A All set-ups FALSE 0 Uint32
2.19.13. 14-** Special Functions
2. How to Programme FC 300 Programming Guide
218
MG.33.M2.02 - VLT
®
