Danfoss FC 300

Par. No. # Parameter description Default value 4-set-up FC 302
only
Change during op-
eration
Conver-
sion index
Type
32-0* Encoder 2 32-00 Incremental Signal Type [1] RS422 (5V TTL) 2 set-ups TRUE - Uint8 32-01 Incremental Resolution 1024 N/A 2 set-ups TRUE 0 Uint32
32-02 Absolute Protocol [0] None 2 set-ups TRUE - Uint8
32-03 Absolute Resolution 8192 N/A 2 set-ups TRUE 0 Uint32
32-05 Absolute Encoder Data Length 25 N/A 2 set-ups TRUE 0 Uint8
32-06 Absolute Encoder Clock Frequency 262.000 kHz 2 set-ups TRUE 0 Uint32
32-07 Absolute Encoder Clock Generation [1] On 2 set-ups TRUE - Uint8
32-08 Absolute Encoder Cable Length 0 m 2 set-ups TRUE 0 Uint16
32-09 Encoder Monitoring [0] Off 2 set-ups TRUE - Uint8
32-10 Rotational Direction [1] No action 2 set-ups TRUE - Uint8
32-11 User Unit Denominator 1 N/A 2 set-ups TRUE 0 Uint32
32-12 User Unit Numerator 1 N/A 2 set-ups TRUE 0 Uint32 32-3* Encoder 1 32-30 Incremental Signal Type [1] RS422 (5V TTL) 2 set-ups TRUE - Uint8 32-31 Incremental Resolution 1024 N/A 2 set-ups TRUE 0 Uint32 32-32 Absolute Protocol [0] None 2 set-ups TRUE - Uint8
32-33 Absolute Resolution 8192 N/A 2 set-ups TRUE 0 Uint32
32-35 Absolute Encoder Data Length 25 N/A 2 set-ups TRUE 0 Uint8
32-36 Absolute Encoder Clock Frequency 262.000 kHz 2 set-ups TRUE 0 Uint32
32-37 Absolute Encoder Clock Generation [1] On 2 set-ups TRUE - Uint8
32-38 Absolute Encoder Cable Length 0 m 2 set-ups TRUE 0 Uint16
32-39 Encoder Monitoring [0] Off 2 set-ups TRUE - Uint8
32-40
Encoder Termination [1] On 2 set-ups TRUE - Uint8
32-5* Feedback Source 32-50 Source Slave [2] Encoder 2 2 set-ups TRUE - Uint8
2.19.17. 32-** MCO Basic Settings
