3-02 Minimum Reference
Range: Function:
0.000
*
[-100000.000 – par.
3-03]
Enter the Minimum Reference. The Minimum Reference is the
lowest value obtainable by summing all references.
Minimum Reference is active only when par. 3-00
Reference
Range
is set to Min.- Max. [0].
The Minimum Reference unit matches:
• The choice of configuration in par 1-00
Configuration
Mode
: for Speed closed loop [1], RPM; for Torque [2],
Nm.
• The unit selected in par. 3-01
Reference/Feedback
Unit
.
3-03 Maximum Reference
Range: Function:
1500.00
0
*
[Par. 3-02 -
100000.000]
Enter the Maximum Reference. The Maximum Reference is the
highest value obtainable by summing all references.
The Maximum Reference unit matches:
• The choice of configuration in par. 1-00
Configuration
Mode
: for Speed closed loop [1], RPM; for Torque [2],
Nm.
• The unit selected in par. 3-01
Reference/Feedback
Unit
.
3-04 Reference Function
Option: Function:
[0]
*
Sum Sums both external and preset reference sources.
[1] External/Preset Use either the preset or the external reference source.
Shift between external and preset via a command on a digital input.
2.6.3. 3-1* References
Parameters for setting up the reference sources.
Select the preset reference(s).
Select Preset ref. bit 0 / 1 / 2 [16], [17] or [18] for the corre-
sponding digital inputs in parameter group 5.1*
Digital Inputs .
3-10 Preset Reference
Array [8]
Range: 0-7
0.00% *
[-100.00 - 100.00 %] Enter up to eight different preset references (0-7) in this pa-
rameter, using array programming. The preset reference is
stated as a percentage of the value Ref
MAX
(par. 3-03 Maximum
