Danfoss FC 301 Operating Guide

17-21 Resolution (Positions/Rev) 17-22 Multiturn Revolutions 17-24 SSI Data Length 17-25 Clock Rate
17-26 SSI Data Format 17-34 HIPERFACE Baudrate
17-5* Resolver Interface 17-50 Poles 17-51 Input Voltage 17-52 Input Frequency 17-53 Transformation Ratio
17-56 Encoder Sim. Resolution
17-59 Resolver Interface
17-6* Monitoring and App. 17-60 Feedback Direction
17-61 Feedback Signal Monitoring
17-7* Position Scaling 17-70 Position Unit
17-71 Position Unit Scale
17-72 Position Unit Numerator 17-73 Position Unit Denominator
17-74 Position Oset
17-75 Position Recovery at Power-up 17-76 Position Axis Mode
17-77 Position Feedback Mode
17-8* Position Homing 17-80 Homing Function 17-81 Home Sync Function
17-82 Home Position 17-83 Homing Speed 17-84 Homing Torque Limit
17-85 Homing Timout
17-9* Position Cong 17-90 Absolute Position Mode 17-91 Relative Position Mode
17-92 Position Control Selection
17-93 Master Oset Selection
17-94 Rotary Absolute Direction
18-** Data Readouts 2 18-3* Analog Readouts 18-36 Analog Input X48/2 [mA] 18-37 Temp. Input X48/4
18-38 Temp. Input X48/7
18-39 Temp. Input X48/10
18-5* Active Alarms/Warnings 18-55 Active Alarm Numbers 18-56 Active Warning Numbers 18-6* Inputs & Outputs 2 18-60 Digital Input 2 30-** Special Features 30-2* Adv. Start Adjust
30-20 High Starting Torque Time [s]
30-21 High Starting Torque Current [%]
30-22 Locked Rotor Protection
30-23 Locked Rotor Detection Time [s]
30-24 Locked Rotor Detection Speed Error
[%]
30-8* Compatibility (I)
30-80 d-axis Inductance (Ld)
30-81 Brake Resistor (ohm)
30-83 Speed PID Proportional Gain
30-84 Process PID Proportional Gain
31-** Bypass Option 31-00 Bypass Mode 31-01 Bypass Start Time Delay
31-02 Bypass Trip Time Delay
31-03 Test Mode Activation
31-10 Bypass Status Word 31-11 Bypass Running Hours 31-19 Remote Bypass Activation
35-** Sensor Input Option 35-0* Temp. Input Mode
35-00 Term. X48/4 Temperature Unit 35-01 Term. X48/4 Input Type
35-02 Term. X48/7 Temperature Unit 35-03 Term. X48/7 Input Type
35-04 Term. X48/10 Temperature Unit
35-05 Term. X48/10 Input Type
35-06 Temperature Sensor Alarm Function
35-1* Temp. Input X48/4 35-14 Term. X48/4 Filter Time Constant
35-15 Term. X48/4 Temp. Monitor
35-16 Term. X48/4 Low Temp. Limit
35-17 Term. X48/4 High Temp. Limit
35-2* Temp. Input X48/7 35-24 Term. X48/7 Filter Time Constant
35-25 Term. X48/7 Temp. Monitor
35-26 Term. X48/7 Low Temp. Limit
35-27 Term. X48/7 High Temp. Limit
35-3* Temp. Input X48/10 35-34 Term. X48/10 Filter Time Constant
35-35 Term. X48/10 Temp. Monitor
35-36 Term. X48/10 Low Temp. Limit
35-37 Term. X48/10 High Temp. Limit
35-4* Analog Input X48/2 35-42 Term. X48/2 Low Current
35-43 Term. X48/2 High Current
35-44 Term. X48/2 Low Ref./Feedb. Value
35-45 Term. X48/2 High Ref./Feedb. Value
35-46 Term. X48/2 Filter Time Constant
42-** Safety Functions 42-1* Speed Monitoring 42-10 Measured Speed Source
42-11 Encoder Resolution 42-12 Encoder Direction
42-13 Gear Ratio 42-14 Feedback Type 42-15 Feedback Filter 42-17 Tolerance Error
42-18 Zero Speed Timer
42-19 Zero Speed Limit
42-2* Safe Input 42-20 Safe Function 42-21 Type 42-22 Discrepancy Time
42-23 Stable Signal Time
42-24 Restart Behaviour
42-3* General
42-30 External Failure Reaction 42-31 Reset Source
42-33 Parameter Set Name
42-35 S-CRC Value 42-36 Level 1 Password
42-4* SS1 42-40 Type 42-41 Ramp Prole 42-42 Delay Time 42-43 Delta T 42-44 Deceleration Rate
42-45 Delta V 42-46 Zero Speed
42-47 Ramp Time 42-48 S-ramp Ratio at Decel. Start 42-49 S-ramp Ratio at Decel. End
42-5* SLS 42-50 Cut O Speed 42-51 Speed Limit 42-52 Fail Safe Reaction
42-53 Start Ramp
42-54 Ramp Down Time
42-6* Safe Fieldbus 42-60 Telegram Selection 42-61 Destination Address 42-8* Status 42-80 Safe Option Status
42-81 Safe Option Status 2
42-82 Safe Control Word
42-83 Safe Status Word
42-85 Active Safe Func.
42-86 Safe Option Info
42-88 Supported Customization File Version
42-89 Customization File Version
42-9* Special 42-90 Restart Safe Option 600-** PROFIsafe 600-22 PROFIdrive/safe Tel. Selected
600-44 Fault Message Counter 600-47 Fault Number
600-52 Fault Situation Counter
601-** PROFIdrive 2 601-22 PROFIdrive Safety Channel Tel. No.
Appendix Operating Guide
MG33AT02 Danfoss A/S © 05/2018 All rights reserved. 71
9 9

Danfoss FC 301 Specifications

General

Type	AC Drive
Output frequency	0-1000 Hz
Enclosure rating	IP20, IP21, IP55
Control method	Sensorless vector control
Communication options	RS-485, CANopen, Profibus DP
Ambient temperature	-10°C to +50°C
Supply voltage	200-240 V, 380-500 V, 525-690 V
Protection class	IP20, IP21, IP55
Cooling method	Forced air
Relative humidity	5% to 95% (non-condensing)
Storage temperature range	-25 to 70 °C (-13 to 158 °F)
