13-10 Comparator Operand
Array [4]
Option: Function:
[31] Counter B
[34] Analog Input x48/2
[35] Temp Input x48/4
[36] Temp Input x48/7
[37] Temp Input x48/10
[40] Analog input x42/1
[41] Analog input x42/3
[42] Analog input x42/5
[50] FALSE
[51] TRUE
[52] Control ready
[53] Drive ready
[54] Running
[55] Reversing
[56] In range
[60] On reference
[61] Below reference, low
[62] Above ref, high
[65] Torque limit
[66] Current Limit
[67] Out of current range
[68] Below I low
[69] Above I high
[70] Out of speed range
[71] Below speed low
[72] Above speed high
[75] Out of feedback range
[76] Below feedback low
[77] Above feedback high
[80] Thermal warning
[82] Mains out of range
[85] Warning
[86] Alarm (trip)
[87] Alarm (trip lock)
[90] Bus OK
[91] Torque limit & stop
[92] Brake fault (IGBT)
[93] Mech. brake control
[94] Safe stop active
[100] Comparator 0
[101] Comparator 1
[102] Comparator 2
[103] Comparator 3
[104] Comparator 4
[105] Comparator 5
[110] Logic rule 0
[111] Logic rule 1
[112] Logic rule 2
[113] Logic rule 3
[114] Logic rule 4
[115] Logic rule 5
13-10 Comparator Operand
Array [4]
Option: Function:
[120] SL Time-out 0
[121] SL Time-out 1
[122] SL Time-out 2
[123] SL Time-out 3
[124] SL Time-out 4
[125] SL Time-out 5
[126] SL Time-out 6
[127] SL Time-out 7
[130] Digital input DI18
[131] Digital input DI19
[132] Digital input DI27
[133] Digital input DI29
[134] Digital input DI32
[135] Digital input DI33
[150] SL digital output A
[151] SL digital output B
[152] SL digital output C
[153] SL digital output D
[154] SL digital output E
[155] SL digital output F
[160] Relay 1
[161] Relay 2
[180] Local referecnce
active
[181] Remote reference
active
[182] Start command
[183] Drive stopped
[185] Drive in hand mode
[186] Drive in auto mode
[187] Start command given
[190] Digital input x30/2
[191] Digital input x30/3
[192] Digital input x30/4
13-11 Comparator Operator
Array [6]
Option: Function:
[0] <
Select [0] < for the result of the evaluation to be
TRUE, when the variable selected in
parameter 13-10 Comparator Operand is smaller
than the xed value in
parameter 13-12 Comparator Value. The result is
FALSE, if the variable selected in
parameter 13-10 Comparator Operand is greater
than the
xed value in
parameter 13-12 Comparator Value.
[1] ≈ (equal)
Select [1] ≈ for the result of the evaluation to be
TRUE, when the variable selected in
parameter 13-10 Comparator Operand is approxi-
Parameter Descriptions
VLT
®
HVAC Drive FC 102
110 Danfoss A/S © 03/2015 All rights reserved. MG11CE02
33
