Danfoss Metasys N2 Programming Guide

Q3-40 Fan functions Q3-41 Pump functions Q3-42 Compressor functions
Parameter 22-60 Broken Belt Function Parameter 22-20 Low Power Auto Set-up Parameter 1-03 Torque Characteristics
Parameter 22-61 Broken Belt Torque Parameter 22-21 Low Power Detection Parameter 1-71 Start Delay
Parameter 22-62 Broken Belt Delay Parameter 22-22 Low Speed Detection Parameter 22-75 Short Cycle Protection
Parameter 4-64 Semi-Auto Bypass Set-up Parameter 22-23 No-Flow Function Parameter 22-76 Interval between Starts
Parameter 1-03 Torque Characteristics Parameter 22-24 No-Flow Delay Parameter 22-77 Minimum Run Time
Parameter 22-22 Low Speed Detection Parameter 22-40 Minimum Run Time Parameter 5-01 Terminal 27 Mode
Parameter 22-23 No-Flow Function Parameter 22-41 Minimum Sleep Time Parameter 5-02 Terminal 29 Mode
Parameter 22-24 No-Flow Delay Parameter 22-42 Wake-up Speed [RPM] 5-12 Terminal 27 Digital Input
Parameter 22-40 Minimum Run Time Parameter 22-43 Wake-up Speed [Hz] Parameter 5-13 Terminal 29 Digital Input
Parameter 22-41 Minimum Sleep Time Parameter 22-44 Wake-up Ref./FB Dierence Parameter 5-40 Function Relay
Parameter 22-42 Wake-up Speed [RPM] Parameter 22-45 Setpoint Boost Parameter 1-73 Flying Start
Parameter 22-43 Wake-up Speed [Hz] Parameter 22-46 Maximum Boost Time Parameter 1-86 Trip Speed Low [RPM]
Parameter 22-44 Wake-up Ref./FB Dierence Parameter 22-26 Dry Pump Function Parameter 1-87 Trip Speed Low [Hz]
Parameter 22-45 Setpoint Boost Parameter 22-27 Dry Pump Delay
–
Parameter 22-46 Maximum Boost Time Parameter 22-80 Flow Compensation
–
Parameter 2-10 Brake Function Parameter 22-81 Square-linear Curve Approxi-
mation
–
2-16 AC brake Max. Current Parameter 22-82 Work Point Calculation
–
Parameter 2-17 Over-voltage Control Parameter 22-83 Speed at No-Flow [RPM]
–
Parameter 1-73 Flying Start Parameter 22-84 Speed at No-Flow [Hz]
–
Parameter 1-71 Start Delay Parameter 22-85 Speed at Design Point [RPM]
–
Parameter 1-80 Function at Stop Parameter 22-86 Speed at Design Point [Hz]
–
Parameter 2-00 DC Hold/Preheat Current Parameter 22-87 Pressure at No-Flow Speed
–
Parameter 4-10 Motor Speed Direction Parameter 22-88 Pressure at Rated Speed
–
–
Parameter 22-89 Flow at Design Point
–
–
Parameter 22-90 Flow at Rated Speed
–
–
Parameter 1-03 Torque Characteristics
–
–
Parameter 1-73 Flying Start
–
Table 2.5 Q3-4 Application Settings
2.1.7
Main Menu Mode
Press [Main Menu] to Select the Main Menu mode. The
below read out appears on the display.
The middle and bottom sections on the display show a list
of parameter groups which can be selected by toggling
the [▲] and [▼] keys.
130BP066.10
1107 RPM
0 -
**
Operation/Display
1 -
**
Load/Motor
2 -
**
Brakes
3 -
**
Reference / Ramps
3.84 A 1 (1)
Main Menu
Illustration 2.27 Main Menu Mode
Each parameter has a name and number which remain the
same regardless of the programming mode. In the Main
Menu mode, the parameters are divided into groups. The
rst digit of the parameter number (from the left) indicates
the parameter group number.
All parameters can be changed in the Main Menu.
However, depending on the conguration
(parameter 1-00 Conguration Mode), some parameters can
be hidden.
How to Programme Programming Guide
MG11CE02 Danfoss A/S © 03/2015 All rights reserved. 21
2 2
