3.10 Parameters: 9-** Main Menu -
PROFIBUS
Parameters in this section are only visible with the VLT
®
PROFIBUS DP MCA 101 option installed.
For PROFIBUS parameter descriptions, see the VLT
®
PROFIBUS DP MCA 101 Programming Guide.
9-15 PCD Write Conguration
Array [10]
Option: Function:
Select the parameters to be
assigned to PCD 3 to 10 of
the telegrams. The number of
available PCDs depends on
the telegram type. The values
in PCD 3 to 10 are then
written to the selected
parameters as data values.
Alternatively, specify a
standard PROFIBUS telegram
in parameter 9-22 Telegram
Selection.
[0] None
[302] Minimum Reference
[303] Maximum Reference
[341] Ramp 1 Ramp Up Time
[342] Ramp 1 Ramp Down Time
[351] Ramp 2 Ramp Up Time
[352] Ramp 2 Ramp Down Time
[380] Jog Ramp Time
[381] Quick Stop Ramp Time
[411] Motor Speed Low Limit
[RPM]
[412] Motor Speed Low Limit
[Hz]
[413] Motor Speed High Limit
[RPM]
[414] Motor Speed High Limit
[Hz]
[416] Torque Limit Motor Mode
[417] Torque Limit Generator
Mode
[553] Term. 29 High Ref./Feedb.
Value
[558] Term. 33 High Ref./Feedb.
Value
[590] Digital & Relay Bus
Control
[593] Pulse Out #27 Bus Control
[595] Pulse Out #29 Bus Control
[597] Pulse Out #X30/6 Bus
Control
9-15 PCD Write Conguration
Array [10]
Option: Function:
[615] Terminal 53 High Ref./
Feedb. Value
[625] Terminal 54 High Ref./
Feedb. Value
[653] Terminal 42 Output Bus
Control
[663] Terminal X30/8 Output
Bus Control
[673] Terminal X45/1 Bus
Control
[683] Terminal X45/3 Bus
Control
[890] Bus Jog 1 Speed
[891] Bus Jog 2 Speed
[894] Bus Feedback 1
[895] Bus Feedback 2
[896] Bus Feedback 3
[1680] Fieldbus CTW 1
[1682] Fieldbus REF 1
[1685] FC Port CTW 1
[1686] FC Port REF 1
9-16 PCD Read Conguration
Option: Function:
Select the parameters to be
assigned to PCD 3 to 10 of
the telegrams. The number
of available PCDs depends
on the telegram type. PCDs
3 to 10 contain the actual
data values of the selected
parameters. For standard
PROFIBUS telegram, see
parameter 9-22 Telegram
Selection.
[0] None
[894] Bus Feedback 1
[895] Bus Feedback 2
[896] Bus Feedback 3
[1397] Alert Alarm Word
[1398] Alert Warning Word
[1399] Alert Status Word
[1500] Operating hours
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601] Reference [Unit]
[1602] Reference [%]
[1603] Status Word
[1605] Main Actual Value [%]
[1609] Custom Readout
[1610] Power [kW]
