5 Parameter Lists
5.1 Parameter Options
5.1.1 Default Settings
Changes during operation
TRUE means that the parameter can be changed while the frequency converter is in operation FALSE means that the
frequency converter must be stopped before a change can be made.
4-Set-up
All set-up: The parameter can be set individually in each of the 4 set-ups, that is 1 single parameter can have 4 dierent
data values.
1 set-up: Data value is the same in all set-ups.
SR
Size related.
N/A
No default value available.
Conversion index
This number refers to a conversion gure used when writing or reading by means of a frequency converter.
Conv.
index
100 75 74 70 67 6 5 4 3 2 1 0 -1 -2 -3 -4 -5 -6
Conv.
factor
1 3600000 3600 60 1/60 1000000 100000 10000 1000 100 10 1 0.1 0.01 0.001 0.0001 0.00001 0.000001
Table 5.1 Conversion Index
Data type Description Type
2 Integer 8 Int8
3 Integer 16 Int16
4 Integer 32 Int32
5 Unsigned 8 Uint8
6 Unsigned 16 Uint16
7 Unsigned 32 Uint32
9 Visible String VisStr
33 Normalised value 2 bytes N2
35 Bit sequence of 16 boolean variables V2
54 Time dierence w/o date TimD
Table 5.2 Conversion Index Description
Parameter Lists Programming Guide
MG11CE02 Danfoss A/S © 03/2015 All rights reserved. 223
5 5
