1-70 PM Start Mode [1] Parking All set-ups TRUE - Uint8
1-71 Start Delay 00 s All set-ups TRUE -1 Uint16
1-72 Start Function ExpressionLimit All set-ups TRUE - Uint8
1-73 Flying Start ExpressionLimit All set-ups TRUE - Uint8
1-77 Compressor Start Max Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
1-78 Compressor Start Max Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-79 Compressor Start Max Time to Trip 5 s All set-ups TRUE -1 Uint8
1-8* Stop Adjustments
1-80 Function at Stop [0] Coast All set-ups TRUE - Uint8
1-81 Min Speed for Function at Stop [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
1-82 Min Speed for Function at Stop [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-86 Trip Speed Low [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
1-87 Trip Speed Low [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-9* Motor Temperature
1-90 Motor Thermal Protection ExpressionLimit All set-ups TRUE - Uint8
1-91 Motor External Fan [0] No All set-ups TRUE - Uint16
1-93 Thermistor Source [0] None All set-ups TRUE - Uint8
5.1.4 2-** Brakes
Param
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
2-0* DC-Brake
2-00 DC Hold/Preheat Current 50 % All set-ups TRUE 0 Uint8
2-01 DC Brake Current 50 % All set-ups TRUE 0 Uint16
2-02 DC Braking Time 10 s All set-ups TRUE -1 Uint16
2-03 DC Brake Cut In Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
2-04 DC Brake Cut In Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
2-06 Parking Current 50 % All set-ups TRUE 0 Uint16
2-07 Parking Time 3 s All set-ups TRUE -1 Uint16
2-1* Brake Energy Funct.
2-10 Brake Function ExpressionLimit All set-ups TRUE - Uint8
2-11 Brake Resistor (ohm) ExpressionLimit All set-ups TRUE -2 Uint32
2-12 Brake Power Limit (kW) ExpressionLimit All set-ups TRUE 0 Uint32
2-13 Brake Power Monitoring [0] O All set-ups TRUE - Uint8
2-15 Brake Check [0] O All set-ups TRUE - Uint8
2-16 AC brake Max. Current ExpressionLimit All set-ups TRUE -1 Uint32
2-17 Over-voltage Control [2] Enabled All set-ups TRUE - Uint8
Parameter Lists
VLT
®
HVAC Drive FC 102
226 Danfoss A/S © 03/2015 All rights reserved. MG11CE02
55
