14-20 Reset Mode ExpressionLimit All set-ups TRUE - Uint8
14-21 Automatic Restart Time 10 s All set-ups TRUE 0 Uint16
14-22 Operation Mode
[0] Normal
operation All set-ups TRUE - Uint8
14-25 Trip Delay at Torque Limit 60 s All set-ups TRUE 0 Uint8
14-26 Trip Delay at Inverter Fault ExpressionLimit All set-ups TRUE 0 Uint8
14-29 Service Code 0 N/A All set-ups TRUE 0 Int32
14-3* Current Limit Ctrl.
14-30 Current Lim Ctrl, Proportional Gain 100 % All set-ups FALSE 0 Uint16
14-31 Current Lim Ctrl, Integration Time ExpressionLimit All set-ups FALSE -3 Uint16
14-32 Current Lim Ctrl, Filter Time ExpressionLimit All set-ups TRUE -4 Uint16
14-4* Energy Optimising
14-40 VT Level 66 % All set-ups FALSE 0 Uint8
14-41 AEO Minimum Magnetisation ExpressionLimit All set-ups TRUE 0 Uint8
14-42 Minimum AEO Frequency 10 Hz All set-ups TRUE 0 Uint8
14-43 Motor Cosphi ExpressionLimit All set-ups TRUE -2 Uint16
14-5* Environment
14-50 RFI Filter [1] On 1 set-up FALSE - Uint8
14-51 DC Link Compensation [1] On 1 set-up TRUE - Uint8
14-52 Fan Control [0] Auto All set-ups TRUE - Uint8
14-53 Fan Monitor [1] Warning All set-ups TRUE - Uint8
14-55 Output Filter [0] No Filter 1 set-up FALSE - Uint8
14-59 Actual Number of Inverter Units ExpressionLimit 1 set-up FALSE 0 Uint8
14-6* Auto Derate
14-60 Function at Over Temperature [0] Trip All set-ups TRUE - Uint8
14-61 Function at Inverter Overload [0] Trip All set-ups TRUE - Uint8
14-62 Inv. Overload Derate Current 95 % All set-ups TRUE 0 Uint16
14-9* Fault Settings
14-90 Fault Level ExpressionLimit 1 set-up TRUE - Uint8
5.1.15 15-** Drive Information
Param
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
15-0* Operating Data
15-00 Operating hours 0 h All set-ups FALSE 74 Uint32
15-01 Running Hours 0 h All set-ups FALSE 74 Uint32
15-02 kWh Counter 0 kWh All set-ups FALSE 75 Uint32
15-03 Power Up's 0 N/A All set-ups FALSE 0 Uint32
15-04 Over Temp's 0 N/A All set-ups FALSE 0 Uint16
15-05 Over Volt's 0 N/A All set-ups FALSE 0 Uint16
15-06 Reset kWh Counter [0] Do not reset All set-ups TRUE - Uint8
15-07 Reset Running Hours Counter [0] Do not reset All set-ups TRUE - Uint8
15-08 Number of Starts 0 N/A All set-ups FALSE 0 Uint32
15-1* Data Log Settings
15-10 Logging Source 0 2 set-ups TRUE - Uint16
15-11 Logging Interval ExpressionLimit 2 set-ups TRUE -3 TimD
15-12 Trigger Event [0] False 1 set-up TRUE - Uint8
15-13 Logging Mode [0] Log always 2 set-ups TRUE - Uint8
15-14 Samples Before Trigger 50 N/A 2 set-ups TRUE 0 Uint8
15-2* Historic Log
15-20 Historic Log: Event 0 N/A All set-ups FALSE 0 Uint8
15-21 Historic Log: Value 0 N/A All set-ups FALSE 0 Uint32
15-22 Historic Log: Time 0 ms All set-ups FALSE -3 Uint32
Parameter Lists
VLT
®
HVAC Drive FC 102
234 Danfoss A/S © 03/2015 All rights reserved. MG11CE02
55
