5.1.22 24-** Application Functions 2
Param
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
24-0* Fire Mode
24-00 Fire Mode Function [0] Disabled 2 set-ups TRUE - Uint8
24-01 Fire Mode Conguration [0] Open Loop All set-ups TRUE - Uint8
24-02 Fire Mode Unit ExpressionLimit All set-ups TRUE - Uint8
24-03 Fire Mode Min Reference ExpressionLimit All set-ups TRUE -3 Int32
24-04 Fire Mode Max Reference ExpressionLimit All set-ups TRUE -3 Int32
24-05 Fire Mode Preset Reference 0 % All set-ups TRUE -2 Int16
24-06 Fire Mode Reference Source [0] No function All set-ups TRUE - Uint8
24-07 Fire Mode Feedback Source [0] No function All set-ups TRUE - Uint8
24-09 Fire Mode Alarm Handling
[1] Trip, Critical
Alarms 2 set-ups FALSE - Uint8
24-1* Drive Bypass
24-10 Drive Bypass Function [0] Disabled 2 set-ups TRUE - Uint8
24-11 Drive Bypass Delay Time 0 s 2 set-ups TRUE 0 Uint16
24-9* Multi-Motor Funct.
24-90 Missing Motor Function [0] O All set-ups TRUE - Uint8
24-91 Missing Motor Coecient 1 0 N/A All set-ups TRUE -4 Int32
24-92 Missing Motor Coecient 2 0 N/A All set-ups TRUE -4 Int32
24-93 Missing Motor Coecient 3 0 N/A All set-ups TRUE -4 Int32
24-94 Missing Motor Coecient 4 0 N/A All set-ups TRUE -3 Int32
24-95 Locked Rotor Function [0] O All set-ups TRUE - Uint8
24-96 Locked Rotor Coecient 1 0 N/A All set-ups TRUE -4 Int32
24-97 Locked Rotor Coecient 2 0 N/A All set-ups TRUE -4 Int32
24-98 Locked Rotor Coecient 3 0 N/A All set-ups TRUE -4 Int32
24-99 Locked Rotor Coecient 4 0 N/A All set-ups TRUE -3 Int32
5.1.23 25-** Cascade Pack Controller
Param
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
25-0* System Settings
25-00 Cascade Controller [0] Disabled 2 set-ups FALSE - Uint8
25-02 Motor Start [0] Direct on Line 2 set-ups FALSE - Uint8
25-04 Pump Cycling [0] Disabled All set-ups TRUE - Uint8
25-05 Fixed Lead Pump [1] Yes 2 set-ups FALSE - Uint8
25-06 Number of Pumps 2 N/A 2 set-ups FALSE 0 Uint8
25-2* Bandwidth Settings
25-20 Staging Bandwidth 10 % All set-ups TRUE 0 Uint8
25-21 Override Bandwidth 100 % All set-ups TRUE 0 Uint8
25-22 Fixed Speed Bandwidth
casco_staging_band
width (P2520) All set-ups TRUE 0 Uint8
25-23 SBW Staging Delay 15 s All set-ups TRUE 0 Uint16
25-24 SBW Destaging Delay 15 s All set-ups TRUE 0 Uint16
25-25 OBW Time 10 s All set-ups TRUE 0 Uint16
25-26 Destage At No-Flow [0] Disabled All set-ups TRUE - Uint8
25-27 Stage Function [1] Enabled All set-ups TRUE - Uint8
25-28 Stage Function Time 15 s All set-ups TRUE 0 Uint16
25-29 Destage Function [1] Enabled All set-ups TRUE - Uint8
25-30 Destage Function Time 15 s All set-ups TRUE 0 Uint16
25-4* Staging Settings
Parameter Lists
VLT
®
HVAC Drive FC 102
242 Danfoss A/S © 03/2015 All rights reserved. MG11CE02
