3 Parameter Descriptions
3.1 Parameter Selection
3.1.1 Main Menu Structure
Parameters for the frequency converter are grouped into
various parameter groups for easy selection of the correct
parameters for optimised operation of the frequency
converter.
To programme most VLT
®
HVAC Drive applications, press
[Quick Menu] and select the parameters under Quick Set-up
and Function Set-ups.
Descriptions and default settings of parameters may be
found in chapter 5 Parameter Lists.
Chapter 3.2 Parameters: 0-** Operation and Display
Chapter 3.3 Parameters: 1-** Load and Motor
Chapter 3.4 Parameters: 2-** Main Menu - Brakes
Chapter 3.5 Parameters: 3-** Main Menu -
Reference/Ramps
Chapter 3.6 Parameters: 4-** Main Menu - Limits/
Warnings
Chapter 3.7 Parameters: 5-** Main Menu - Digital
In/Out
Chapter 3.8 Parameters: 6-** Main Menu - Analog
In/Out
Chapter 3.9 Parameters: 8-** Main Menu -
Communications and Options
Chapter 3.10 Parameters: 9-** Main Menu -
PROFIBUS
Chapter 3.11 Parameters: 10-** Main Menu - CAN
Fieldbus
Chapter 3.12 Parameters: 11-** Main Menu -
LonWorks
Chapter 3.13 Parameters: 13-** Main Menu - Smart
Logic
Chapter 3.14 Parameters: 14-** Main Menu - Special
Functions
Chapter 3.15 Parameters: 15-** Main Menu - Drive
Information
Chapter 3.16 Parameters: 16-** Main Menu - Data
Readouts
Chapter 3.17 Parameters: 18-** Main Menu - Data
Readouts 2
Chapter 3.18 Parameters: 20-** Main Menu - FC
Closed Loop
Chapter 3.19 Parameters: 21-** Main Menu -
Extended Closed Loop
Chapter 3.20 Parameters: 22-** Application
Functions
Chapter 3.21 Parameters: 23-** Time-based
Functions
Chapter 3.22 Parameters: 24-** Application
Functions 2
Chapter 3.23 Parameters: 25-** Cascade Controller
Chapter 3.24 Parameters: 26-** Analog I/O Option
MCB 109
Chapter 3.25 Parameters: 30-** Special Features
Parameter Descriptions
VLT
®
HVAC Drive FC 102
24 Danfoss A/S © 03/2015 All rights reserved. MG11CE02
