Danfoss Metasys N2 Programming Guide

16-09 Custom Readout
0 CustomRea-
doutUnit All set-ups FALSE -2 Int32
16-1* Motor Status
16-10 Power [kW] 0 kW All set-ups FALSE 1 Int32
16-11 Power [hp] 0 hp All set-ups FALSE -2 Int32
16-12 Motor Voltage 0 V All set-ups FALSE -1 Uint16
16-13 Frequency 0 Hz All set-ups FALSE -1 Uint16
16-14 Motor current 0 A All set-ups FALSE -2 Int32
16-15 Frequency [%] 0 % All set-ups FALSE -2 N2
16-16 Torque [Nm] 0 Nm All set-ups FALSE -1 Int32
16-17 Speed [RPM] 0 RPM All set-ups FALSE 67 Int32
16-18 Motor Thermal 0 % All set-ups FALSE 0 Uint8
16-22 Torque [%] 0 % All set-ups FALSE 0 Int16
16-26 Power Filtered [kW] 0 kW All set-ups FALSE 0 Int32
16-27 Power Filtered [hp] 0 hp All set-ups FALSE -3 Int32
16-3* Drive Status
16-30 DC Link Voltage 0 V All set-ups FALSE 0 Uint16
16-32 Brake Energy /s 0 kW All set-ups FALSE 0 Uint32
16-33 Brake Energy /2 min 0 kW All set-ups FALSE 0 Uint32
16-34 Heatsink Temp. 0 °C All set-ups FALSE 100 Uint8
16-35 Inverter Thermal 0 % All set-ups FALSE 0 Uint8
16-36 Inv. Nom. Current ExpressionLimit All set-ups FALSE -2 Uint32
16-37 Inv. Max. Current ExpressionLimit All set-ups FALSE -2 Uint32
16-38 SL Controller State 0 N/A All set-ups FALSE 0 Uint8
16-39 Control Card Temp. 0 °C All set-ups FALSE 100 Uint8
16-40 Logging Buer Full [0] No All set-ups TRUE - Uint8
16-43 Timed Actions Status
[0] Timed Actions
Auto All set-ups TRUE - Uint8
16-49 Current Fault Source 0 N/A All set-ups TRUE 0 Uint8
16-5* Ref. & Feedb.
16-50 External Reference 0 N/A All set-ups FALSE -1 Int16
16-52 Feedback[Unit] 0 ProcessCtrlUnit All set-ups FALSE -3 Int32
16-53 Digi Pot Reference 0 N/A All set-ups FALSE -2 Int16
16-54 Feedback 1 [Unit] 0 ProcessCtrlUnit All set-ups FALSE -3 Int32
16-55 Feedback 2 [Unit] 0 ProcessCtrlUnit All set-ups FALSE -3 Int32
16-56 Feedback 3 [Unit] 0 ProcessCtrlUnit All set-ups FALSE -3 Int32
16-58 PID Output [%] 0 % All set-ups TRUE -1 Int16
16-6* Inputs & Outputs
16-60 Digital Input 0 N/A All set-ups FALSE 0 Uint16
16-61 Terminal 53 Switch Setting [0] Current All set-ups FALSE - Uint8
16-62 Analog Input 53 0 N/A All set-ups FALSE -3 Int32
16-63 Terminal 54 Switch Setting [0] Current All set-ups FALSE - Uint8
16-64 Analog Input 54 0 N/A All set-ups FALSE -3 Int32
16-65 Analog Output 42 [mA] 0 N/A All set-ups FALSE -3 Int16
16-66 Digital Output [bin] 0 N/A All set-ups FALSE 0 Int16
16-67 Pulse Input #29 [Hz] 0 N/A All set-ups FALSE 0 Int32
16-68 Pulse Input #33 [Hz] 0 N/A All set-ups FALSE 0 Int32
16-69 Pulse Output #27 [Hz] 0 N/A All set-ups FALSE 0 Int32
16-70 Pulse Output #29 [Hz] 0 N/A All set-ups FALSE 0 Int32
16-71 Relay Output [bin] 0 N/A All set-ups FALSE 0 Int16
16-72 Counter A 0 N/A All set-ups TRUE 0 Int32
16-73 Counter B 0 N/A All set-ups TRUE 0 Int32
16-75 Analog In X30/11 0 N/A All set-ups FALSE -3 Int32
16-76 Analog In X30/12 0 N/A All set-ups FALSE -3 Int32
Parameter Lists
VLT
®
HVAC Drive FC 102
236 Danfoss A/S © 03/2015 All rights reserved. MG11CE02
55
