Output Pins Available on Individual PLUS+1 Modules
PLUS+1 Module DOUT
(2A)
DOUT
(3 A)
HDOUT
(6 A)
DOUT/
PVGpwr
(3 A)
PWMOUT/
DOUT/
PVGOUT (3
A)
HPWMOUT/
DOUT (6 A)
HPWMOUT/
DOUT (10 A)
MC012-010/012 2
MC012-026/029 2
MC018-010/012 4 2
MC024-010/011/012/014 4
MC024-020/021/022/024 8
MC038-010 2 3 3 5
MC050-010/012 3 3 10
MC050-020/022 6 2 6
MC050-055/05B 1 2
MC088-015/01B 13 6 3 10
IOX012-010 2
IOX024-020 8
OX012-010 6
OX024-010 4 2 10
PLUS+1 control modules feature user-configurable output pin parameters. Output pin parameters are
configured using PLUS+1 GUIDE templates.
Refer to module data sheets for maximum output current ratings of individual modules and MC038-010
and MC088-015/01B power planes. The total output current for any PLUS+1 module must not exceed the
maximum allowable current specified in the module data sheet. In the case of MC038-010 and
MC088-015/01B modules, both the total output current for an individual power plane and the total
output for the module must not exceed the limits specified on the module data sheets.
Warning
Unintended movement of the machine or mechanism may cause injury to the technician or bystanders.
The module will be powered up if battery voltage is applied to the module’s output pin. To protect
against unintended movement, secure the machine.
Caution
Warranty will be voided if module is damaged by significant current driven back through an output pin.
Digital (DOUT) and Digital/PVG Reference Power (DOUT/PVEpwr)
Digital outputs can source up to 3 A. The exception is MC038-010 controller, DOUT pins are limited to 2 A.
Technical Information PLUS+1® Controller Family
Inputs/Outputs Types and Specifications
520L0719 • Rev PB • Feb 2014 15
