Danfoss PLUS+1 Series

•
Current outputs for MC050-010, MC050-020, MC088-015, and OX024-010 module
•
DOUT and DOUT/PVG Pwr pins are pair limited and a function of temperature.
Output per pair is: 6 A maximum at 25 C [77 F]. Output per pair is 4 A maximum at 70° C [158˚ F]
•
MC050-010 pairs are: C1p31 and C1p32, C1p33 and C1p34, C1p35 and C1p36
•
MC050-020 pairs are: C1p33 and C1p34, C1p35 and C1p36, C1p37 and C1p38, C1p39 and C1p40
•
MC088-015 pairs are:
Power plane C2p35: C1p31 and C1p32, C1p33 and C1p34
Power plane C2p36: C1p35 and C1p36
Power plane C2p37: C2p1 and C2p7, C2p2 and C2p3, C2p4 and C2p5, C2p30 and C2p33
Power plane C2p38: C2p6 and C2p12
•
OX024-010 pairs are: C1p6 and C1p7, C1p8 and C1p9, C1p10 and C1p11
•
Example: at a module temperature of 70˚ C [158˚ F], if C1p31 is sourcing 2.5 A, the most current that
can be sourced on its paired pin C1p32 is 1.5 A
General
Description Comment
Configuration Sourcing only.
Type Linear switching.
Short circuit to ground protection Non-damage, current/thermal limit with status indication;
automatic latch off /resume.
Open circuit detection Fault indication provided. The GUIDE Pin Status requires a load
of 500 mA to be connected or an open fault will be declared.
Parallel operation Digital outputs from the same module are capable of being
connected together such that the net current rating is the sum
of the individual ratings; timing is resolved by the operating
system; diagnostic capability is maintained.
Shut off Processor control with hardware WatchDog override.
Specifications
Description Units Minimum Maximum Comment
Allowed voltage at pin Vdc 0 36 See caution statement, page 17.
Output voltage, energized state Vdc Vbatt-1.0 Vbatt Over all load conditions.
Output voltage, off state Vdc 0 0.1 At Rload=200 Ω
Output current range for a status bit
to read OK
A 0.5 3 See note regarding pair, above.
Do not connect a digital output to battery+ (back drive) without a series diode.
High Current Digital (HDOUT)
High current digital outputs can source up to 6 A.
General
Description Comment
Configuration Sourcing only.
