Danfoss PLUS+1 Series

Environmental Testing Criteria
General Product Ratings
Description Units Minimum Maximum
Comment
Operating temperature ˚C [˚F] -40 [-40] 70 [158] Maximum operating temperature for
MC012-026/029 modules is 105° C (221°
F).
Storage temperature ˚C [˚F] -40 [-40] 85 [185] Maximum storage temperature for
MC012-026/029 modules is 105° C (221°
F).
Allowable module supply voltage Vdc 9 36* Minimum allowable supply voltage for
the MC038-010 module CPU power pin
is 6 Vdc.
* MC050-055/05B input voltage
maximum is limited to 16 Vdc.
Module sensor supply voltage Vdc 4.8 5.2 Sensor voltage drops below the
minimum value if module supply
voltage < 9 Vdc. Exception for
MC050-055/05B and MC024-01A, see
Sensor Power Supply Ratings, page 23.
Analog input voltage levels Vdc 36* * MC050-055/05B input voltage
maximum is limited to 16 Vdc.
Allowable output load current (per
pin)
A See individual module date sheets.
Module allowable total output
current
A See individual module data sheets.
All modules Ingress Protection (IP)
rating**
IP 67
** The PLUS+1 modules IP 67 rating is
only valid when the module mating
connector is in place and unused
connector pin positions have sealing
plugs installed.
All modules CE rating CE compliant.
PLUS+1 Module Environmental Testing Criteria
Climate Environment
Description Applicable standard Comment
Storage temperature IEC 60068-2-1, test Ab, IEC
60068-2-2 test Bb
Operating temperature IEC 60068-2-1, test Ab, IEC
60068-2-2 test Bd
Thermal cycle IEC 60068-2-2, test Na, IEC
60068-2-38 (partial)
Humidity IEC 60068-2-78, IEC
60068-2-30 test Db
Damp heat steady state and cyclic.
Degree of protection IEC 60529
Technical Information PLUS+1® Controller Family
Product Ratings
520L0719 • Rev PB • Feb 2014 25
