Danfoss PLUS+1 Series User Manual

Chemical Environment
Description Applicable standard Comment
Salt mist IEC 60068-2-58 test Kb
Chemical resistance ISO 16750-5
Mechanical Environment
Description Applicable standard Comment
Vibration IEC 60068-2-6 test Fc,
IEC6008-2-64 test Fh
Bump IEC 60068-2-29 test Eb
Shock IEC 60068-2-27 test Ea
Free fall IEC 60068-2-32 test Ed
Electrical/Electromagnetic
Description Applicable standard Comment
EMC emission ISO 13766, SAE J1113-13 Electromagnetic compatibility for earth moving
machinery.
EMC immunity ISO 13766 Electromagnetic compatibility for earth moving
machinery.
Electrostatic discharge EN 60-1 000-4-2
Auto electrical transients ISO 7637-2, ISO 7637-3
Short circuit protection Danfoss test Inputs and outputs survive continuous short
circuit. Normal function resumes when short is
removed.
Reversed polarity protection Danfoss test Survives reverse polarity at supply voltage for at
least five minutes.
Modules Housing
PLUS+1 module housings feature a snap together assembly that is tamper-proof. Once assembled at the
factory, the housing cannot be opened for service.
Opening the modules housing will void the factory warranty.
Technical Information PLUS+1® Controller Family
Product Ratings
26 520L0719 • Rev PB • Feb 2014

Danfoss PLUS+1 Series Specifications

General

Temperature Range	-40°C to +85°C
Ingress Protection	IP67
Communication Interfaces	CAN, Ethernet, USB, RS232, RS485
Operating System	PLUS+1 GUIDE
Programming Language	PLUS+1 GUIDE (Graphical User Integrated Development Environment)
Memory	Flash, RAM
Inputs	Analog, Digital
Outputs	PWM, High-Side
Protection	Overvoltage, Undervoltage, Reverse Polarity, Short Circuit
Operating Voltage	8-32 VDC
