Danfoss PLUS+1 Series User Manual

Danfoss Mating Connector Part Information
Description 12 pin
module
18 pin
module
24 pin
module
38 pin
module
50 pin
module
88 pin
module
Mating
connector bag
assembly (20
to 24 AWG)
10100944 — — 10100945 — — 10100946 10105649
Mating
connector bag
assembly (16
to 20 AWG)
10102025 10102025 10102023 11027919 10102024 11071844
Danfoss Crimp Extraction Tool Part Information
Description Part number
Crimp tool for 20 to 24 AWG 10100745
Crimp tool for 16 to 20 AWG 10102028
Extraction tool Deutsch 114010; 12 AWG 11068808
Extraction tool Deutsch 0144-240-2005; 16 to 20, 20 to 24 AWG 10100744
PLUS+1 module mating connectors may be mated 10 times.
Recommended torque for the Deutsch® mating connector retaining fastener on 38 and 50 pin connectors
is 20 lb•in (2.26 N•m).
Product Installation
Mounting
PLUS+1 12, 24, 38, and 50 pin modules can be mounted in one of three ways:
•
End (bulkhead) installation
•
Up to 3 units stacked on one another
•
Individually side mounted
MC018-XXX modules are designed for panel mounting only.
MC088-XXX modules are designed for bulkhead mounting only.
In each case, care must be taken to insure that the module connector is positioned so that moisture
drains away from the connector. If the module is side or stack mounted, provide a drip loop in the
harness. If the module is mounted vertically, the connector should be on the bottom of the module.
Provide strain relief for mating connector wires.
C
Caution
Module damage may occur. Use caution when installing MC050-XXX modules. Due to the size of the
mating connector wire bundle, it is possible to twist off the end cap of the module if excessive pressure is
applied during the installation of harness strain relief.
Suggested Fasteners and Recommended Installation Torque
Mounting method Recommended OD Recommended torque
Bulkhead mount; multiple units stacked; single 6.0 mm (.25 in) 9.49 N•m (7 ft•lb)
Technical Information PLUS+1® Controller Family
Product Installation and Start-up
28 520L0719 • Rev PB • Feb 2014

Danfoss PLUS+1 Series Specifications

General

Temperature Range	-40°C to +85°C
Ingress Protection	IP67
Communication Interfaces	CAN, Ethernet, USB, RS232, RS485
Operating System	PLUS+1 GUIDE
Programming Language	PLUS+1 GUIDE (Graphical User Integrated Development Environment)
Memory	Flash, RAM
Inputs	Analog, Digital
Outputs	PWM, High-Side
Protection	Overvoltage, Undervoltage, Reverse Polarity, Short Circuit
Operating Voltage	8-32 VDC
