Estimated Usage of Memory and Communication Resources (continued)
Description IX012-010 IX024-010 OX012-010 OX024-010 IOX012-010 IOX024-20
update and 250K
bus speed)
Estimated
module bus load
(using 70 ms
updates and 250K
bus speed)
2% 5% 3% 8% 4% 8%
RAM usage on
MC012-XXX
9% 12% 9% 14% 9% 17%
RAM usage on
MC018-010
9% 12% 9% 14% 9% 17%
RAM usage on
MC024-010
9% 12% 9% 14% 9% 17%
RAM usage on
MC024-011
9% 12% 9% 14% 9% 17%
RAM usage on
MC038-010
9% 12% 9% 18% 9% 26%
RAM usage on
MC050-010,
MC050-020
1% 1% 1% 2% 1% 2%
RAM usage on
MC050-055
1% 1% 1% 2% 1% 0%
RAM usage on
MC088-010
1% 1% 1% 2% 1% 2%
ROM usage on
MC012-XXX
8% 11% 12% 18% 10% 19%
ROM usage on
MC018-010
8% 11% 12% 18% 10% 20%
ROM usage on
MC024-010
8% 11% 12% 18% 10% 20%
ROM usage on
MC024-011
3% 4% 4% 6% 3% 7%
ROM usage on
MC038-010
8% 11% 12% 18% 10% 21%
ROM usage on
MC050-010,
MC050-020
3% 4% 4% 6% 3% 8%
ROM usage on
MC050-055
3% 4% 4% 6% 3% 8%
ROM usage on
MC088-015
3% 4% 4% 6% 3% 7%
Technical Information PLUS+1® Controller Family
Controller Area Network Specifications
520L0719 • Rev PB • Feb 2014 21
