PVB 100/16 combination valve stack dimensions, mm [in] (continued)
Number of
PVB 100
(down)
Number of PVB 16
1 2 3 4 5 6 7 8 9 10 11
5 L1 364
[14.33]
404
[15.91]
444
[17.48]
484
[19.06]
524
[20.63]
564
[22.20]
604
[23.78]
644
[25.35]
684
[26.93]
724
[28.50]
-
L2 428
[16.85]
477
[18.78]
503
[19.80]
550
[21.65]
599
[23.58]
624
[24.57]
673
[26.50]
722
[28.43]
746
[29.37]
795
[31.30]
-
L3 272 [10.71]
6 L1 412
[16.22]
452
[17.80]
492
[19.37]
532
[20.94]
572
[22.52]
612
[24.09]
652
[25.67]
692
[27.24]
732
[28.82]
- -
L2 476
[18.74]
525
[20.67]
551
[21.69]
598
[23.54]
647
[25.47]
672
[26.46]
721
[28.39]
770
[30.31]
794
[31.26]
- -
L3 320 [12.60]
7 L1 460
[18.11]
500
[19.69]
540
[21.26]
580
[22.83]
620
[24.41]
660
[25.98]
700
[27.56]
740
[29.13]
- - -
L2 524
[20.63]
573
[22.56]
599
[23.58]
646
[25.43]
695
[27.36]
720
[28.35]
769
[30.28]
818
[32.20]
- - -
L3 368 [14.49]
8 L1 508
[20.00]
548
[21.57]
588
[23.15]
628
[24.72]
668
[26.30]
708
[27.87]
748
[29.45]
- - - -
L2 572
[22.52]
621
[24.45]
647
[25.47]
694
[27.32]
743
[29.25]
768
[30.24]
817
[32.17]
- - - -
L3 416 [16.38]
Weight for a PVG 100/16 valve stack
The combined weight of a PVG 100/16 valve stack can be defined like this:
(Numbers of PVB 100 x 7) + (numbers of PVB 16 x 3.67) + 10 = Weight in kg
(Numbers of PVB 100 x 9.37) + (numbers of PVB 16 x 8.09) + 22 = Weight in lb
