Danfoss PVG 16 Technical Information

PVG 256/16 Dimensions
The table of PVB 256 and PVB 16 combination valve stack dimensions overview table with accompanying
drawing.
L1
L3
95 [3.74]
132 [5.20]
L2
PVB 256/16 combination valve stack dimensions, mm [in]
Number
of PVB
256
(down)
Number of PVB 16
1 2 3 4 5 6 7 8 9 10 11
1 L1 193
[7.60]
233
[9.17]
273
[10.75]
313
[12.32]
353
[13.90]
393
[15.47]
433
[17.05]
473
[18.62]
513
[20.20]
553
[21.78]
593
[23.35]
L2 321,5
[12.66]
358,5
[14.11]
406,5
[16.01]
443,5
[17.46]
479,5
[18.88]
528,5
[20.81]
564,5
[22.22]
600,5
[23.64]
649,5
[25.57]
685,5
[26.99]
734,5
[28.92]
L3 118,5 [4.67]
2 L1 285
[11.22]
325
[12.80]
365
[14.37]
405
[15.94]
445
[17.52]
485
[19.09]
525
[20.67]
565
[22.224
]
605
[23.82]
— —
L2 406,5
[16.01]
455,5
[17.93]
491,5
[19.35]
528,5
[20.81]
576,5
[22.70]
612,5
[24.11]
649,5
[25.57]
697,5
[27.46]
734,5
[28.92]
— —
L3 204,5 [8.05]
3 L1 371
[14.61]
411
[16.18]
451
[17.76]
491
[19.33]
531
[20.91]
571
[22.48]
611
[24.06]
— — — —
L2 491,5
[19.35]
540,5
[21.28]
576,5
[22.70]
612,5
[24.11]
661,5
[26.04]
697,5
[27.46]
734,5
[28.92]
— — — —
L3 290,5 [11.44]
4 L1 457
[17.99]
497
[19.57]
537
[21.14]
577
[22.72]
617
[24.29]
— — — — — —
L2 588,5
[23.17]
625,5
[24.63]
661,5
[26.04]
709,5
[27.93]
746,5
[29.39]
— — — — — —
L3 376,5 [14.82]
5 L1 543
[21.38]
583
[22.95]
623
[24.53]
— — — — — — — —
L2 673,5
[26.52
709,5
[27.93]
746,5
[29.93]
— — — — — — — —
L3 462,5 [18.21]
Technical Information
PVG 16 Proportional Valve Group
PVG 16 Combinations Valve Stack Dimensions
106 |
©
Danfoss | December 2018 BC00000211en-000901
