Danfoss PVG 16 Technical Information

PVG 32/16 Combinations
The table of PVB 32 and PVB 16 modules combination, the total length depending on the amount of
valve groups.
PVB 16
Modules in mm [in] 1 2 3 4 5 6 7 8 9 10 11
PVB 32
1
159
[6.26]
199
[7.83]
239
[9.41]
279
[10.98]
319
[12.56]
359
[14.13]
399
[15.71]
439
[17.28]
479
[18.86]
519
[20.43]
559
[22.01]
2
207
[8.15]
247
[9.72]
287
[11.30]
327
[12.87]
367
[14.45]
407
[16.02]
447
[17.60]
487
[19.17]
527
[20.74]
567
[22.32]
607
[23.90]
3
255
[10.04]
295
[11.61]
335
[13.19]
375
[14.76]
415
[16.34]
455
[17.91]
495
[19.49]
535
[21.06]
575
[22.64]
615
[24.21]
655
[25.79]
4
303
[11.93]
343
[13.50]
383
[15.08]
423
[16.65]
463
[18.23]
503
[19.80]
543
[21.38]
583
[22.95]
623
[24.53]
663
[26.10]
-
5
351
[13.82]
391
[15.39]
431
[16.97]
471
[18.54]
511
[20.12]
551
[21.69]
591
[23.27]
631
[24.84]
671
[26.42]
- -
6
399
[15.71]
439
[17.28]
479
[18.86]
519
[20.43]
559
[22.01]
599
[23.58]
639
[25.16]
- - - -
7
447
[17.60]
487
[19.17]
527
[20.75]
567
[22.32]
607
[23.90]
647
[25.47]
- - - - -
8
495
[19.49]
535
[21.06]
575
[22.64]
615
[24.21]
655
[25.79]
- - - - - -
9
543
[21.38]
583
[22.95]
623
[24.53]
663
[26.10]
- - - - - - -
10
591
[23.27]
631
[24.84]
671
[26.42]
- - - - - - - -
11
639
[25.16]
- - - - - - - - - -
