Danfoss PVG 16 Technical Information

PVG 16 Modules Overview
PVG proportional valve group shown in the exploded view illustration for a quick modules navigation.
PVG 16 Modules Assembly Overview
PVM
PVP PVE
PVH/CoversPVBPVBS
PVS PVHC
PVAS
PVG Modules Navigation:
PVP Inlet Modules on page 9
PVB Basic Modules on page 38
PVBS Main Spools on page 62
PVM Manual Actuation on page 69
PVE Electro-hydraulic Actuation on page 75
PVH Hydraulic Actuation on page 71
PVHC Electro-Hydraulic Actuation on page 73
PVS End Plates on page 86
PVAS Stay Bolts on page 92
