Danfoss PVG 16 Technical Information

PVPX technical data (continued)
Max. coil surface temperature
155°C [311°F]
Thread size
3/4-16 UNF
Technical specification
Parameter Minimum Recommended range Maximum
Fluid temperature
-30°C [-22°F] 30 to 60°C [86 to 140°F] 90° [194°F]
Fluid viscosity
4 mm
2
/s [39 SUS] 12 to 75 mm
2
/s [65 to 347 SUS] 460 mm
2
/s [2128 SUS]
Fluid cleanliness
23/19/16 (according to ISO 4406)
Operating temperature
Ambient: -30 to 60°C [-22 to 140°F]
Part numbers for PVPX
Part numbers for PVPX, NO and NC configuration
Part number Configuration Voltage Supply Connector IP Rating
157B4236
NO 12 V
DC
1x2 DIN IP 65
157B4238
NO 24 V
DC
157B4246
NC 12 V
DC
157B4248
NC 24 V
DC
157B4976
NC 26 V
DC
157B4981
NO 12 V
DC
1x2 AMP IP 66
157B4982
NO 24 V
DC
157B4983
NC 12 V
DC
157B4984
NC 24 V
DC
11180766
NO 12 V
DC
1x2 DEUTSCH IP 67
11180767
NO 24 V
DC
11180768
NC 12 V
DC
11180769
NC 24 V
DC
11225108
NO 26 V
DC
11225109
NC 26 V
DC
Part numbers for PVPX, NOMO configuration
Part number Manual Override Voltage Supply Connector IP Rating
157B4256
PUSH 12 V
DC
1x2 DIN IP 65
157B4257
PUSH & TURN 12 V
DC
157B4258
PUSH 24 V
DC
157B4259
PUSH & TURN 24 V
DC
157B4260
PUSH 26 V
DC
157B4985
PUSH 12 V
DC
1x2 AMP IP 66
157B4986
PUSH 24 V
DC
Technical Information
PVG 16 Proportional Valve Group
PVP Inlet Module Accessories
34 |
©
Danfoss | December 2018 BC00000211en-000901
