Danfoss PVG 16 Technical Information

PVG 16 Dimensions
The table of PVB 16 valve stack dimensions overview table with accompanying drawing.
L1
91 [3.58]
71.5 [2.81]
38.5 [1.52]
18.5 [0.73]
261.5 [10.3]
78.5 [3.09]
110 [4.33]
303.8 [11.96]
22.5°
60 [2.36]
95 [3.74]
191.3 [7.53]
121.6 [4.79]
73.5 [2.89]
62.5 [2.46]
25 [0.98]
L2
PVB 16 dimensions (12 sections)
Number of
PVB 16
1 2 3 4 5 6 7 8 9 10 11 12
L1 mm
[in]
74
[2.91]
114
[4.49]
154
[6.06]
194
[7.64]
234
[9.21]
274
[10.79]
314
[12.36]
354
[13.94]
394
[15.51]
434
[17.09]
474
[18.66]
514
[20.24]
L2 mm
[in]
140
[5.51]
189
[7.44]
213
[8.39]
262
[10.31]
311
[12.24]
336
[13.23]
385
[15.16]
434
[17.09]
458
[18.03]
507
[19.96]
551
[21.69]
576
[22.68]
Technical Information
PVG 16 Proportional Valve Group
PVG 16 Combinations Valve Stack Dimensions
©
Danfoss | December 2018 BC00000211en-000901 | 97
