PVB 120/16 combination valve stack dimensions, mm [in] (continued)
Number of
PVB 120
(down)
Number of PVB 16 modules
1 2 3 4 5 6 7 8 9 10 11
5 L1 552
[21.73]
592
[23.31]
632
[24.8]
672
[26.46]
712
[28.03]
752
[29.61]
792
[31.18]
832
[32.76]
872
[34.33]
912
[35.91]
-
L2 608
[23.94]
657
[25.87]
681
[26.81]
730
[28.74]
779
[30.67]
804
[31.65]
853
[33.58]
902
[35.51]
926
[36.46]
975
[38.39]
-
L3 272 [10.71]
6 L1 619
[24.37]
659
[25.94]
699
[27.52]
739
[29.09]
779
[30.67]
819
[32.24]
859
[33.82]
899
[35.39]
939
[36.97]
- -
L2 673
[26.50]
722
[28.43]
746
[29.37]
795
[31.30]
844
[33.23]
869
[34.21]
918
[36.14]
967
[38.07]
991
[39.02]
- -
L3 320 [12.60]
7 L1 686
[27.01]
726
[28.58]
766
[30.16]
806
[31.73]
846
[33.31]
886
[34.88]
926
[36.46]
966
[38.03]
- - -
L2 738
[29.06]
787
[30.98]
811
[31.93]
860
[33.86]
909
[35.79]
934
[36.77]
983
[38.70]
1032
[40.63]
- - -
L3 368 [14.49]
8 L1 753
[29.65]
793
[31.22]
833
[32.80]
873
[34.37]
913
[35.94]
953
[37.52]
993
[39.09]
- - - -
L2 803
[31.61]
852
[33.54]
876
[34.49]
925
[36.42]
974
[38.35]
999
[39.33]
1048
[41.26]
- - - -
L3 639 [25.16]
There is a horizontal difference 62.5 mm [2.46 in] in the mounting plane of the PVG 120/PVG 16.
The PVG 120 interface module is large sized.
It is necessary to have at least one PVG 32 module between the PVGI and the first PVG 16 slice.
