PVLP shock valve characteristics
(l/min)
[US gal/min]
P
Q
Q
(bar)
[psi]
20 40 60 80 100 120 140
5
10 15 20 25 30 35 40 45
400
350
300
250
200
150
100
50
0
5000
4000
3000
2000
1000
0
6000
0
0
PVB pressure compensated P-line and T-line characteristics
Q
Q
P
[psi]
(l/min)
[US gal/min]
5
4,5
4
3,5
3
2,5
2
1,5
1
0,5
0
50
50
40
30
20
10
0
70
75
25
5 10
15
20 25
30
35
40
100
125
150
60
0
0
Port A/B
T-line
P-line
P
(bar)
Part numbers for Uncompensated PVB with PVLP
Part number A/B-port PVLP Check valve
11101424
3/8” BSP 1 Yes
11106754
3/8” BSP 1 —
11101425
3/4” – 16 UNF 1 Yes
11106755
3/4” – 16 UNF 1 —
Technical Information
PVG 16 Proportional Valve Group
PVB Basic Modules
©
