Danfoss PVG 16 Technical Information

Technical data (continued)
Fluid consumption Neutral 0.04 l/min [0.01 US gal/min]
Locked position 0.04 l/min [0.01 US gal/min]
Actuating 0.6 l/min [0.16 US gal/min]
Fluid temperature Ambient Storage -50 to +90°C [-58 to +194°F]
Ambient Operating -40 to +90°C [-40 to +194°F]
Fluid viscosity Operating range 12 to 75 mm
2
/sec [65 to 347 SUS]
Minimum 4 mm
2
/sec [39 SUS]
Maximum 460 mm
2
/sec [2128 SUS]
Fluid cleanliness Minimum 18/16/13 (according to ISO 4406)
LED characteristic
Color LED characteristic Description
Green constant No error – Actuating
Green flashing @ 1.5 Hz Neutral – Power save
Red constant Internal error
Red flashing @ 1.5 Hz External or Float error
Part numbers for PVEA/PVEA-F/PVEA-CI
Part number Type Connector Protection Class Interface Functionality
11103692
PVEA 1x4 DEUTSCH IP 67 — Standard
11106795
PVEA-F 1x4 DEUTSCH IP 67 — Float B-port
11121945
PVEA-CI 1x4 DEUTSCH IP 67 J1939/ISObus Standard
11149437
PVEA-CI 1x4 DEUTSCH IP 67 CANopen Standard
