Frame Size 075
Manual Displacement Control (MDC) Endcap Side Ports, Option 60
248.2
[9.77]
Port L1
Case drain
use highest
port as outlet
1-1/16-12UN-2B
81.3
[3.20]
172.2
[6.78]
Gauge port M5
servo pressure
9/16-18UNF-2B
Gauge port M4
servo pressure
9/16-18UNF-2B
7.9 [0.31]
41.6
[1.64]
27.76
[1.093]
View "Y"
57.15 [2.25]
Ports A and B
1 – 6000 psi
split flange boss
per SAE J518
(Code 62)
7/16-14UNC-2B
20 [0.79]
minimum full thread
3.8
[0.15]
14.2
[0.56]
141.7 [5.58]
Port L2
155.7
[6.13]
124.2 [4.89]
port L1
139.7
[5.50]
Approximate
center of gravity
Gauge port M2
System pressure B
9/16-18UNF-2B
9.4
[0.37]
"X"
"Z"
"Y"
12.45
[0.49]
7.9
[0.31]
±0.25
[±0.01]
129 [5.08]
port B
306,1
(12.05)
Gauge port M1
system pressure A
9/16-18UNF-2B
94.5 [3.72]
port A
262.6 [10.34]
Port S
Ø 126.7
[Ø 5]
0 -0.05
[+0.000] [-0.002]
93.7
[3.69]
155.7
[6.13]
40.6
[1.60]
57.25
[2.254]
114.5
[4.50]
91.7 [3.61]
port L2
Approximate
center of gravity
Port L2
case drain
1-1/16-12UN-2B
View "Z"
99.3
[3.91]
110.7
[4.36]
"W"
Ø 14.27
[Ø 0.562]
Rotation
CCW
CW
(4x)
(2x)
Gauge port M3
charge pressure
9/16-18UNF-2B
Multifunction
valve
Charge pressure
relief valve
View "X"
Multifunction
valve
Port S: charge pump inlet
1-5/16-12UN-2B
84.0
[3.31]
65
[2.56]
Ø 6.73±0.13
[Ø 0.265±0.005]
R 25.4±0.3
[R 1.0±0.01]
R 50.8±0.3
[R 2.0±0.01]
3x
B
A
28°
minimum
28°
minimum
Neutral
position
Torque applied to control handle shaft
not to exceed 17 N•m [150 lbf•in]
Maximum
displacement
Maximum
displacement
Manual displacement control handle
dimensions
Control MDC, option MA
2
M3
M2M10M1
A
B
M4M5
P102 046
+0.25
-0.18
[+0.010]
[-0.007]
41.67
[1.64]
12.70
[0.50]
Ø 6.33
[Ø 0.249]
4.78
[0.188]
External charge plug
1 5/16-12 UNF
Technical Information Series 90 Axial Piston Pumps
Installation Drawings
520L0603 • Rev 0804 • March 2016 57
