Series 90 Master Model Code
R Size M P J G N F L H T W Y Z K
S90
Size
042 055 075 100 130 180 250
042 42 cc [2.56 in
3
] max. displacement per revolution O
055 55 cc [3.36 in
3
] max. displacement per revolution O
075 75 cc [4.58 in
3
] max. displacement per revolution O
100 100 cc [6.10 in
3
] max. displacement per revolution O
130 130 cc [7.93 in
3
] max. displacement per revolution O
180 180 cc [10.98 in
3
] max. displacement per revolution O
250 250 cc [15.26 in
3
] max. displacement per revolution O
R Type and Rotation
042 055 075 100 130 180 250
R Right Hand [CW] O O O O O O O
L Left Hand [CCW] O O O O O O O
M Controls
042 055 075 100 130 180 250
CA cover plate without feedback link, no control O O O O O O
DC 3 positon F-N-R solenoid control (12 V , DC) DIN- connector O O O O O O
DD 3 positon F-N-R solenoid control (24 V , DC) DIN- connector O O O O O O O
HF HDC 2, std. porting, 3,0 - 11 BAR (44 - 160 PSI) O O O O O O O
KA EDC, MS connector, std. porting, dual coil (14 - 85 mA) O O O O O O O
KN EDC, MS connector, std. porting, 643 Ohm single coil (4 - 20 mA) O O O O O O O
KT EDC, Deutsch connector, std porting, dual coil ( 14 - 85 mA) O O O O O O
KP EDC, Weatherpack connector, std. porting, dual coil (14 - 85mA) O O O O O O O
MA MDC O O O O O O O
MB MDC with neutral start switch O O O O O O O
FA
electrohydraulic displacement control without feedback link, 12V with AMP Minitimer
connector, proportional solenoid with pressure reducing valve ( 25 bar) (NFPE control)
O O O
FB
electrohydraulic displacement control without feedback link, 24V with AMP Minitimer
connector, proportional solenoid with pressure reducing valve ( 25 bar) (NFPE control)
O O O
FC
electrohydraulic displacement control without feedback link, 12V with AMP Minitimer
connector, proportional solenoid with pressure reducing valve ( 32 bar) (NFPE control)
O O O
FD
electrohydraulic displacement control without feedback link, 24V with AMP Minitimer
connector, proportional solenoid with pressure reducing valve ( 32 bar) (NFPE control)
O O O
FG
electrohydraulic displacement control without feedback link, 12V with AMP Minitimer
connector, proportional solenoid with pressure reducing valve ( 32 bar) fast response
(NFPE control)
O O O O
FH
electrohydraulic displacement control without feedback link, 24V with AMP Minitimer
connector, proportional solenoid with pressure reducing valve ( 32 bar) fast response
(NFPE control)
O O O O
FK
electrohydraulic displacement control without feedback link, 12V with AMP Minitimer
connector, proportional solenoid with pressure reducing valve ( 25 bar) (NFPE control)
O
FL
electrohydraulic displacement control without feedback link, 24V with AMP Minitimer
connector, proportional solenoid with pressure reducing valve ( 25 bar) (NFPE control)
O
FM
electrohydraulic displacement control without feedback link, 12V with AMP Minitimer
connector, proportional solenoid with pressure reducing valve ( 32 bar) fast response
(NFPE control)
O
FN
electrohydraulic displacement control without feedback link, 24V with AMP Minitimer
connector, proportional solenoid with pressure reducing valve ( 32 bar) fast response
(NFPE control)
O
Series 90 Master Model
Code
O
O
Technical Information Series 90 Axial Piston Pumps
Master Model Code
520L0603 • Rev 0804 • March 2016 21
