Auxiliary mounting pad - options AB, BC, CD, DE, BB
B
A
B
M2
M1
A
4 threads
1/2-13UNC-2B
22 [0.87] deep
View "X"
146
[5.75]
146
[5.75]
SAE B-B, option BB
425.65
[16.76]
408
[16.06]
23.3
[0.92]
For O-ring
Ø 94.92 x 2.62
[Ø 3.737 x 0.103]
"X"
Ø 101.65
[Ø 4.002]
Coupling spline data:
Pitch diameter = 23.8125 [0.9375]
Pressure angle = 30°
Number of teeth = 15
Pitch = 16/32
ANSI B92.1-1970, class 6,
fillet root side fit
Length of spline = 24.59 [0.96]
+ 0.13
- 0.00
[+0.005]
[- 0.000]
SAE D, option DE
View "X"
4 threads
3/4-10UNC-2B
41 [1.6] deep
161.6
[6.36]
161.6
[6.36]
439.22
[17.29]
415.62
[16.36]
For O-ring
Ø 153 x 3.0
[Ø 6.02 x 0.118]
"X"
Ø 152.45
[Ø 6.002]
+ 0.13
- 0.00
[+0.005]
[- 0.000]
50.84
[2.00]
Coupling spline data:
Pitch diameter = 41.275 [1.625]
Pressure angle = 30°
Number of teeth = 13
Pitch = 8/16
ANSI B92.1-1970, class 6,
fillet root side fit
Length of spline =
25.22 [0.993]
2
2
M5
M4
M2
M5
M4
M1
P102 054
