Dimensions
Frame size F1 F2 F3 F4 maximum F5 maximum F6 maximum F7 maximum
042 174.5 [6.87] 262.6 [10.34] 201.4 [7.93] 207.7 [8.12] 112.7 [4.44] 152.7 [6.01] 168.0 [6.61]
055 174.5 [6.87] 262.6 [10.34] 240.9 [8.19] 209.6 [8.25] 114.3 [4.50] 154.3 [6.07] 169.6 [6.68]
075 174.5 [6.87] 262.6 [10.34] 253.2 [9.67] 214.4 [8.44] 119.1 [4.69] 159.1 [6.26] 174.4 [6.86]
075 NFPE 174.5 [6.87] 262.4 [10.34] 253.7 [9.99] 214 [8.441] 119 [4.691] 159 [6.264] 174 [6.866]
100 174.5 [6.87] 262.6 [10.34] 280.7 [11.05] 223.0 [8.78] 127.7 [5.03] 167.7 [6.60] 183.0 [7.20]
130 174.5 [6.87] 262.6 [10.34] 299.9 [11.81] 223.0 [9.17] 137.7 [5.03] 177.7 [6.99] 193.0 [7.60]
180 - - 327.8 [12.90] - 182.0 [7.16] 236.8 [9.32] 259.2 [10.2]
250 - - 342.8 [13.49] - 182.0 [7.16] 236.8 [9.32] 259.2 [10.2]
Technical Information Series 90 Axial Piston Pumps
Installation Drawings
520L0603 • Rev 0804 • March 2016 87
