Danfoss VLT AutomationDrive FC 300 User Manual

P132 - P200 380-480 V type gG
P250 - P400 380-480 V type gR
Table 4.32
UL Compliance
380-480 V, frame sizes D, E and F
The fuses below are suitable for use on a circuit capable of
delivering 100,000 Arms (symmetrical), 240 V, or 480 V, or
500 V, or 600 V depending on the frequency converter
voltage rating. With the proper fusing the frequency
converter Short Circuit Current Rating (SCCR) is 100,000
Arms.
Size/
Type
Bussmann
E1958
JFHR2**
Bussmann
E4273
T/JDDZ**
SIBA
E180276
JFHR2
LittelFuse
E71611
JFHR2**
Ferraz-
Shawmut
E60314
JFHR2**
Bussmann
E4274
H/JDDZ**
Bussmann
E125085
JFHR2*
Internal
Option
Bussmann
P132 FWH-
400
JJS-
400
2061032.40 L50S-400 A50-P400 NOS-
400
170M4012 170M4016
P160 FWH-
500
JJS-
500
2061032.50 L50S-500 A50-P500 NOS-
500
170M4014 170M4016
P200 FWH-
600
JJS-
600
2062032.63 L50S-600 A50-P600 NOS-
600
170M4016 170M4016
Table 4.33 Frame size D, Line fuses, 380-480 V
Size/Type Bussmann PN* Rating Ferraz Siba
P250 170M4017 700 A, 700 V 6.9URD31D08A0700 20 610 32.700
P315 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
P355 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
P400 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
Table 4.34 Frame size E, Line fuses, 380-480 V
Size/Type Bussmann PN* Rating Siba
Internal Bussmann
Option
P450 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
P500 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
P560 170M7082 2000 A, 700 V 20 695 32.2000 170M7082
P630 170M7082 2000 A, 700 V 20 695 32.2000 170M7082
Table 4.35 Frame size F, Line fuses, 380-480 V
Size/Type
Bussmann PN* Rating Siba
P450 170M8611 1100 A, 1000 V 20 781 32.1000
P500 170M8611 1100 A, 1000 V 20 781 32.1000
P560 170M6467 1400 A, 700 V 20 681 32.1400
P630 170M6467 1400 A, 700 V 20 681 32.1400
Table 4.36 Frame size F, Inverter module DC Link Fuses, 380-480 V
*170M fuses from Bussmann shown use the -/80 visual indicator, -
TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size
and amperage may be substituted for external use
**Any minimum 500 V UL listed fuse with associated current rating
may be used to meet UL requirements.
Supplementary fuses
Frame size Bussmann PN* Rating
D, E and F KTK-4 4 A, 600 V
Table 4.37 SMPS Fuse
