Danfoss VLT AutomationDrive FC 300 User Manual

Size/Type Bussmann PN* LittelFuse Rating
P132-P250, 380-480 V KTK-4 4 A, 600 V
P315-P630, 380-480 V KLK-15 15A, 600 V
Table 4.38 Fan Fuses
Size/Type
Bussmann PN* Rating Alternative Fuses
P450-P630, 380-480 V 2.5-4.0 A LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual
Element, Time Delay, 6A
P450-P630, 380-480 V 4.0-6.3 A LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual
Element, Time Delay, 10 A
P450-P630, 380-480 V 6.3 - 10 A LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual
Element, Time Delay, 15 A
P450-P630, 380-480 V 10 - 16 A LPJ-25 SP or SPI 25 A, 600 V Any listed Class J Dual
Element, Time Delay, 25 A
Table 4.39 Manual Motor Controller Fuses
Frame size Bussmann PN* Rating Alternative Fuses
F LPJ-30 SP or SPI 30 A, 600 V Any listed Class J Dual Element, Time Delay, 30 A
Table 4.40 30 A Fuse Protected Terminal Fuse
Frame size Bussmann PN* Rating Alternative Fuses
D LP-CC-8/10 0.8A, 600V Any listed Class CC, 0.8A
E LP-CC-1 1/2 1.5A, 600V Any listed Class CC, 1.5A
F LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual Element, Time Delay, 6 A
Table 4.41 Control Transformer Fuse
Frame size Bussmann PN* Rating
F GMC-800MA 800 mA, 250 V
Table 4.42 NAMUR Fuse
Frame size Bussmann PN* Rating Alternative Fuses
F LP-CC-6 6 A, 600 V Any listed Class CC, 6 A
Table 4.43 Safety Relay Coil Fuse with PILS Relay
4.6.15
Mains Disconnectors - Frame Size D, E and F
Frame size Power & Voltage Type
D P132-P200 380-480 V OT400U12-91
E P250 380-480 V ABB OETL-NF600A
E P315-P400 380-480 V ABB OETL-NF800A
F P450 380-480 V Merlin Gerin NPJF36000S12AAYP
F P500-P630 380-480 V Merlin Gerin NRK36000S20AAYP
Table 4.44
How to Install VLT Automation Low Harmonic Drive Operating Instructions
MG34O202 - VLT
®
is a registered Danfoss trademark 49
4 4
