Operation keys
for local control are found at the bottom of the control
panel.
130BP046.10
Hand
on
O
Auto
on
Reset
Illustration 5.12
[Hand On]
enables control of the frequency converter via the GLCP.
[Hand On] also starts the motor, and it is now possible to
give the motor speed reference by means of the arrow
keys. The key can be [1] Enabled or [0] Disabled via
0-40 [Hand on] Key on LCP.
The following control signals will still be active when
[Hand On] is activated:
•
[Hand On] - [Off] - [Auto On]
•
Reset
•
Coasting stop inverse (motor coasting to stop)
•
Reversing
•
Set-up select lsb - Set-up select msb
•
Stop command from serial communication
•
Quick stop
•
DC brake
NOTE
External stop signals activated by means of control signals
or a serial bus will override a “start” command via the LCP.
[Off]
stops the connected motor (when pressed on the
frequency converter LCP) or the filter (when pressed on
the filter LCP). The key can be [1] Enabled or [0] Disabled
via 0-41 [Off] Key on LCP. If no external stop function is
selected and the [Off] key is inactive the motor can only
be stopped by disconnecting the mains supply.
[Auto On]
enables the frequency converter to be controlled via the
control terminals and/or serial communication. When a
start signal is applied on the control terminals and/or the
bus, the frequency converter will start. The key can be [1]
Enabled or [0] Disabled via 0-42 [Auto on] Key on LCP.
NOTE
[Auto On] must be pressed on the filter LCP.
NOTE
An active HAND-OFF-AUTO signal via the digital inputs has
higher priority than the control keys [Hand On] – [Auto
On].
[Reset]
is used for resetting the frequency converter or filter after
an alarm (trip). The key can be [1] Enabled or [0] Disabled
via 0-43 [Reset] Key on LCP.
The parameter shortcut
can be carried out by holding down the [Main Menu] key
for 3 seconds. The parameter shortcut allows direct access
to any parameter.
5.1.3 Changing Data
1. Press [Quick Menu] or [Main Menu].
2.
Use [
▲
] and [
▼
] to find parameter group to edit.
3. Press [OK].
4.
Use [
▲
] and [
▼
] to find parameter to edit.
5. Press [OK].
6.
Use [
▲
] and [
▼
] to select correct parameter
setting. Or, to move to digits within a number,
use [◄] and [►]. Cursor indicates digit selected to
change. [
▲
] key increases the value, [
▼
] key
decreases the value.
7. Press [Cancel] to disregard change, or press [OK]
to accept change and enter new setting.
5.1.4
Changing a Text Value
If the selected parameter is a text value, change the text
value by means of the [
▲
]/[
▼
] keys.
[
▲
] increases the value, and [
▼
] decreases the value. Place
the cursor on the value to be saved and press [OK].
130BP068.10
740RPM
0 -01 Language
[0] English
10.64 A 1 [1]
0-0
*
Basic Settings
Illustration 5.13 Display Example.
How to Operate the Low Harm... VLT Automation Low Harmonic Drive Operating Instructions
MG34O202 - VLT
®
is a registered Danfoss trademark 63
5 5
