Danfoss VLT AutomationDrive FC 301 Instruction Manual

Type designation P5K5 P7K5 P11K
High/Normal overload
1)
HO NO HO NO HO NO
Typical shaft output (hp [kW]) 7.5 [5.5] 10 [7.5] 10 [7.5] 15 [11] 15 [11] 20 [15]
Enclosure protection rating IP20 B3 B3 B4
Enclosure protection rating IP21, IP55, IP66 B1 B1 B2
Output current
Continuous (200–240 V) [A] 24.2 30.8 30.8 46.2 46.2 59.4
Intermittent (60 s overload) (200–240 V) [A] 38.7 33.9 49.3 50.8 73.9 65.3
Continuous kVA (208 V) [kVA] 8.7 11.1 11.1 16.6 16.6 21.4
Maximum input current
Continuous (200–240 V) [A] 22.0 28.0 28.0 42.0 42.0 54.0
Intermittent (60 s overload) (200–240 V) [A] 35.2 30.8 44.8 46.2 67.2 59.4
Additional specifications
IP20 maximum cable cross-section
2)
for line power, brake, motor
and load sharing [mm
2
] ([AWG])
10, 10, - (8, 8, -) 10, 10, - (8, 8, -) 35, -, - (2, -, -)
IP21 maximum cable cross-section
2)
for line power, brake and
load sharing [mm
2
] ([AWG])
16, 10, 16 (6, 8, 6) 16, 10, 16 (6, 8, 6) 35, -, - (2, -, -)
IP21 maximum cable cross-section
2)
for motor [mm
2
] ([AWG])
10, 10, - (8, 8, -) 10, 10, - (8, 8, -) 35, 25, 25 (2, 4, 4)
Maximum cable cross-section
2)
for disconnect [mm
2
] ([AWG])
16,10,10 (6,8,8)
Estimated power loss at rated maximum load (hp [W])
3)
0.321 [239] 0.416 [310]
0.497
[371]
0.689
[514]
0.621
[463]
0.807
[602]
Efficiency
4)
0.96 0.96 0.96
Table 8.2 Line Power Supply 200–240 V, P5K5-P11K
Specifications Instruction Manual
MG33AP22 Danfoss A/S © Rev. 09/2014 All rights reserved. 53
8 8
