Danfoss VLT AutomationDrive FC 301 Instruction Manual

8.1.3 Line Power Supply 525–600 V (FC 302 only)
Type designation PK75 P1K1 P1K5 P2K2 P3K0 P4K0 P5K5 P7K5
Typical shaft output (hp [kW]) 1.0 [0.75] 1.5 [1.1] 2 [1.5] 3 [2.2] 4 [3] 5 [4] 7.5 [5.5] 10 [7.5]
Enclosure protection rating IP20, IP21 A3 A3 A3 A3 A3 A3 A3 A3
Enclosure protection rating IP55 A5 A5 A5 A5 A5 A5 A5 A5
Output current
Continuous (525–550 V) [A] 1.8 2.6 2.9 4.1 5.2 6.4 9.5 11.5
Intermittent (525–550 V) [A] 2.9 4.2 4.6 6.6 8.3 10.2 15.2 18.4
Continuous (551–600 V) [A] 1.7 2.4 2.7 3.9 4.9 6.1 9.0 11.0
Intermittent (551–600 V) [A] 2.7 3.8 4.3 6.2 7.8 9.8 14.4 17.6
Continuous kVA (525 V) [kVA] 1.7 2.5 2.8 3.9 5.0 6.1 9.0 11.0
Continuous kVA (575 V) [kVA] 1.7 2.4 2.7 3.9 4.9 6.1 9.0 11.0
Maximum input current
Continuous (525–600 V) [A] 1.7 2.4 2.7 4.1 5.2 5.8 8.6 10.4
Intermittent (525–600 V) [A] 2.7 3.8 4.3 6.6 8.3 9.3 13.8 16.6
Additional specifications
Maximum cable cross-section
2)
for line power,
motor, brake and load sharing [mm
2
] ([AWG])
4,4,4 (12,12,12)
(min. 0.2 (24))
Maximum cable cross-section
2)
for disconnect
[mm
2
] ([AWG])
6,4,4 (10,12,12)
Estimated power loss at rated maximum load
(hp [W])
3)
0.047
[35]
0.067
[50]
0.087
[65]
0.123
[92]
0.164
[122]
0.195
[145]
0.262
[195]
0.350
[261]
Efficiency
4)
0.97 0.97 0.97 0.97 0.97 0.97 0.97 0.97
Table 8.7 Line Power Supply 525–600 V (FC 302 only), PK75-P7K5
