Danfoss VLT AutomationDrive FC 301 Instruction Manual

Type designation P11K P15K P18K P22K P30K
High/Normal overload
1)
HO NO HO NO HO NO HO NO HO NO
Typical shaft output (hp [kW]) 15 [11] 20 [15] 20 [15] 25 [18.5] 25 [18.5] 30 [22] 30 [22] 40 [30] 40 [30] 50 [37]
Enclosure protection rating IP20 B3 B3 B4 B4 B4
Enclosure protection rating IP21,
IP55, IP66
B1 B1 B2 B2 C1
Output current
Continuous (525–550 V) [A] 19 23 23 28 28 36 36 43 43 54
Intermittent (525–550 V) [A] 30 25 37 31 45 40 58 47 65 59
Continuous (551–600 V) [A] 18 22 22 27 27 34 34 41 41 52
Intermittent (551–600 V) [A] 29 24 35 30 43 37 54 45 62 57
Continuous kVA (550 V) [kVA] 18.1 21.9 21.9 26.7 26.7 34.3 34.3 41.0 41.0 51.4
Continuous kVA (575 V) [kVA] 17.9 21.9 21.9 26.9 26.9 33.9 33.9 40.8 40.8 51.8
Maximum input current
Continuous at 550 V [A] 17.2 20.9 20.9 25.4 25.4 32.7 32.7 39 39 49
Intermittent at 550 V [A] 28 23 33 28 41 36 52 43 59 54
Continuous at 575 V [A] 16 20 20 24 24 31 31 37 37 47
Intermittent at 575 V [A] 26 22 32 27 39 34 50 41 56 52
Additional specifications
IP20 maximum cable cross-section
2)
for line power, brake, motor and
load sharing [mm
2
] ([AWG])
10, 10, - (8, 8, -) 10, 10, - (8, 8, -) 35, -, - (2, -, -) 35, -, - (2, -, -) 35, -, - (2, -, -)
IP21, IP55, IP66 maximum cable
cross-section
2)
for line power, brake
and load sharing [mm
2
] ([AWG])
16, 10, 10 (6, 8, 8) 16, 10, 10 (6, 8, 8) 35, -, - (2, -, -) 35, -, - (2, -, -) 50, -, - (1, -, -)
IP21, IP55, IP66 maximum cable
cross-section
2)
for motor
[mm
2
] ([AWG])
10, 10, - (8, 8, -) 10, 10, - (8, 8, -) 35, 25, 25 (2, 4, 4) 35, 25, 25 (2, 4, 4) 50, -, - (1, -, -)
Maximum cable cross-section
2)
for
disconnect [mm
2
] ([AWG])
16, 10, 10
(6, 8, 8)
50, 35, 35
(1, 2, 2)
Estimated power loss
at rated maximum load (hp [W])
3)
0.295
[220]
0.402
[300]
0.402
[300]
0.496
[370]
0.496
[370]
0.590
[440]
0.590
[440]
0.805
[600]
0.805
[600]
0.992
[740]
Efficiency
4)
0.98 0.98 0.98 0.98 0.98
Table 8.8 Line Power Supply 525–600 V (FC 302 only), P11K-P30K
Specifications Instruction Manual
MG33AP22 Danfoss A/S © Rev. 09/2014 All rights reserved. 59
8 8
