Recommended maximum fuse
Power
(hp [kW])
Max.
prefuse
Bussmann
E52273
RK1/JDDZ
Bussmann
E4273
J/JDDZ
Bussmann
E4273
T/JDDZ
SIBA
E180276
RK1/JDDZ
Littelfuse
E81895
RK1/JDDZ
Ferraz-
Shawmut
E163267/E2137
RK1/JDDZ
Ferraz-
Shawmut
E2137
J/HSJ
15 [11] 30 A KTS-R-30 JKS-30 JKJS-30 5017906-030 KLS-R-030 A6K-30-R HST-30
20–25
[15–18.5]
45 A KTS-R-45 JKS-45 JJS-45 5014006-050 KLS-R-045 A6K-45-R HST-45
30 [22] 60 A KTS-R-60 JKS-60 JJS-60 5014006-063 KLS-R-060 A6K-60-R HST-60
40 [30] 80 A KTS-R-80 JKS-80 JJS-80 5014006-080 KLS-R-075 A6K-80-R HST-80
50 [37] 90 A KTS-R-90 JKS-90 JJS-90 5014006-100 KLS-R-090 A6K-90-R HST-90
60 [45] 100 A KTS-R-100 JKS-100 JJS-100 5014006-100 KLS-R-100 A6K-100-R HST-100
75 [55] 125 A KTS-R-125 JKS-125 JJS-125 2028220-125 KLS-150 A6K-125-R HST-125
100 [75] 150 A KTS-R-150 JKS-150 JJS-150 2028220-150 KLS-175 A6K-150-R HST-150
Table 8.23 525–690 V, Enclosure Types B and C
8.8 Connection Tightening Torques
Torque (in-lb [Nm])
Enclosure Line power Motor
DC
connection
Brake Ground Relay
A2 15.93 [1.8] 15.93 [1.8] 15.93 [1.8] 15.93 [1.8] 26.55 [3] 5.31 [0.6]
A3 15.93 [1.8] 15.93 [1.8] 15.93 [1.8] 15.93 [1.8] 26.55 [3] 5.31 [0.6]
A4 15.93 [1.8] 15.93 [1.8] 15.93 [1.8] 15.93 [1.8] 26.55 [3] 5.31 [0.6]
A5 15.93 [1.8] 15.93 [1.8] 15.93 [1.8] 15.93 [1.8] 26.55 [3] 5.31 [0.6]
B1 15.93 [1.8] 15.93 [1.8] 13.28 [1.5] 13.28 [1.5] 26.55 [3] 5.31 [0.6]
B2 39.83 [4.5] 39.83 [4.5] 32.8 [3.7] 32.8 [3.7] 26.55 [3] 5.31 [0.6]
B3 15.93 [1.8] 15.93 [1.8] 15.93 [1.8] 15.93 [1.8] 26.55 [3] 5.31 [0.6]
B4 39.83 [4.5] 39.83 [4.5] 39.83 [4.5] 39.83 [4.5] 26.55 [3] 5.31 [0.6]
C1 88.51 [10] 88.51 [10] 88.51 [10] 88.51 [10] 26.55 [3] 5.31 [0.6]
C2
123.91/212.42
[14/24]
1)
123.91/212.42
[14/24]
1)
123.91 [14] 123.91 [14] 26.55 [3] 5.31 [0.6]
C3 88.51 [10] 88.51 [10] 88.51 [10] 88.51 [10] 26.55 [3] 5.31 [0.6]
C4
123.91/212.42
[14/24]
1)
123.91/212.42
[14/24]
1)
123.91 [14] 123.91 [14] 26.55 [3] 5.31 [0.6]
Table 8.24 Tightening Terminals
1) For different cable dimensions x/y, where x ≤ 4/0 AWG [95 mm
2
] and y ≥ 4/0 AWG [95 mm
2
].
Specifications Instruction Manual
76 Danfoss A/S © Rev. 09/2014 All rights reserved. MG33AP22
